WCX 1335 Top-Drive Conveyor
Portable Grain Belt Conveyor
Assembly Manual
Electric and Hydraulic Drives
Original Instructions
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 30998 R1
Revised: July 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WCX 1335 and is the answer not in the manual?

Questions and answers

Summary of Contents for Westfield WCX 1335

  • Page 1 WCX 1335 Top-Drive Conveyor Portable Grain Belt Conveyor Assembly Manual Electric and Hydraulic Drives Original Instructions Read this manual before using product. Failure to Part Number: 30998 R1 follow instructions and safety precautions can Revised: July 2018 result in serious injury, death, or property...
  • Page 2 New in this Manual The following changes have been made in this revision of the manual: Description Section Figure 29 on page 41 Update short cross-member...
  • Page 3: Table Of Contents

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR CONTENTS 1. Introduction ............................4 2. Safety............................... 5 2.1. Safety Alert Symbol and Signal Words..................5 2.2. General Product Safety ......................5 2.3. Moving Conveyor Belt Safety....................6 2.4. Rotating Parts Safety........................ 6 2.5.
  • Page 4: Introduction

    1 1 . . I I n n t t r r o o d d u u c c t t i i o o n n This manual describes how to assemble a Westfield Portable Grain Belt Conveyor.
  • Page 5: Safety

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY 2 2 . . S S a a f f e e t t y y 2.1. Safety Alert Symbol and Signal Words This safety alert symbol indicates important safety messages in this manual. When you see this symbol, be alert to the possibility of injury or death, carefully read the message that follows, and inform others.
  • Page 6: Moving Conveyor Belt Safety

    2. SAFETY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2.3. Moving Conveyor Belt Safety • DO NOT step on or touch moving conveyor belt. • Shut off and lock out power to adjust, service, or clean. 2.4. Rotating Parts Safety •...
  • Page 7: Electric Motor Safety

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY 2.5.1 Electric Motor Safety Power Source • Electric motors and controls shall be installed and serviced by a qualified electrician and must meet all local codes and standards. • A magnetic starter should be used to protect your motor.
  • Page 8: Hydraulic Power Safety

    2. SAFETY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2.5.2 Hydraulic Power Safety Power Source • Refer to the rules and regulations applicable to the power source operating your hydraulic drive. • Do not connect or disconnect hydraulic lines while system is under pressure.
  • Page 9: Tire Safety

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY 2.6. Tire Safety Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion that may result in serious injury or death.
  • Page 10: Safety Equipment

    2. SAFETY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Coveralls • Wear coveralls to protect skin. Hard Hat • Wear a hard hat to help protect your head. 2.8. Safety Equipment The following safety equipment should be kept on site: Fire Extinguisher •...
  • Page 11 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY decals and the areas or particular functions that the decals apply to, as well as the safety precautions that must be taken to avoid serious injury, death, or damage.
  • Page 12 2. SAFETY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 3. Hydraulic Top Drive Safety Decal Locations 30998 R1...
  • Page 13 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY Table 1. Safety Decals Part Number Description 20817 DANGER ELECTROCUTION HAZARD To prevent death or serious injury: • When operating or moving, keep equipment away from overhead power lines and devices.
  • Page 14 2. SAFETY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Table 1 Safety Decals (continued) Part Number Description 20807 WARNING To prevent serious injury or death: • Read and understand the manual before assembling, operating, or maintaining the equipment.
  • Page 15 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY Table 1 Safety Decals (continued) Part Number Description 20804 WARNING ENTANGLEMENT HAZARD To prevent serious injury or death: • Keep body, hair, and clothing away from rotating pulleys, belts, chains, and sprockets.
  • Page 16 2. SAFETY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Table 1 Safety Decals (continued) Part Number Description 20805 WARNING HIGH PRESSURE FLUID HAZARD Hydraulic fluid can cause serious injury if it Hydraulic fluid can cause serious injury if it penetrates the skin.
  • Page 17 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. SAFETY Table 1 Safety Decals (continued) Part Number Description 17109 CAUTION For proper raising and lowering of equipment: • After lowering equipment, always tighten brake lock by turning winch handle clockwise at least two clicks.
  • Page 18: Features

    3. FEATURES WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 3 3 . . F F e e a a t t u u r r e e s s This section covers the main features of the conveyor.
  • Page 19: Assembly

    Report missing or damaged parts immediately to ensure that proper credit is received from Westfield or your distributor/dealer, and to ensure that any missing parts can be shipped quickly to avoid holding up the assembly process.
  • Page 20: Required Tools

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4.3. Required Tools • 2–3 • 1 pipe stand(s) tape measure(s) (100' [30.5 m]) • 2 • 1 sawhorse(s) ratchet strap (1200 lb [544.3 kg]) • 1 • 2...
  • Page 21: Attach The Hitch

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Table 3. Tube Connection Components Item Description 7/16" Locknut 7/16" x 1" Bolt Figure 5. Typical Tube Connection 4.6. Attach the Hitch This procedure describes the installation of the hitch on the hopper weldment.
  • Page 22: Assemble The Hand Winch

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 6. Hitch Components 4.7. Assemble the Hand Winch Winch handle must be assembled as per instructions. Failure to do so will result in sudden winch failure causing damage to equipment and/or personal injury.
  • Page 23: Install The Hand Winch

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 7. Attaching Hand Winch Handle 4.8. Install the Hand Winch 1. Attach the winch (2) to the winch mount bracket (1) with 3/8" whiz nuts (3) (see Figure Table 6.
  • Page 24: Install The Track Shoe

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 8. Installing the Hand Winch 4.9. Install the Track Shoe 1. Slide the track shoe (2) onto the track by sliding shoe down from the discharge end of conveyor. See Figure for proper orientation of track shoe.
  • Page 25: Assemble The Weather Guard

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 9. Installing the Frame Slider 4.10. Assemble the Weather Guard 1. Install the types of weather guard sections in which are indicated by the identifier letters as shown on your particular conveyor model schematic that follows.
  • Page 26 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Table 8. Types of Weather Guard Identifier Type of Weather Guard Section 5' (1.52 m) Standard 5' (1.52 m) Flared Table 9. Components to Install Weather Guard onto the Tube Bracket...
  • Page 27: Install The Belt

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 11. Weather Guard Section Locations (WCX 1335) 4.11. Install the Belt This section describes how to install the conveyor belt in the tube. Refer to the packing slip for the length of the conveyor belt used in the installation.
  • Page 28 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 13. Fish Tape Connected to a Short Piece of Belt Thread the Conveyor Belt 1. From the spout end, pull the fish tape until the belt emerges from the spout.
  • Page 29 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 15. Conveyor Belt Around Hopper Roller Item Description Hopper Roller Take-up Bolt The conveyor belt is now ready to be connected. Connect the Conveyor Belt 1. Attach a strap puller (1) to each end of the belt and secure with vise-grips (2).
  • Page 30: Install The Weather Guard Mount Bars

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 16 Using a Strap Puller (continued) Item Description Strap Puller Vise Grip Belt Lacing Lacing Pin 4. On both corners of the trailing edge of the belt, trim a tapered notch to prevent fraying.
  • Page 31 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY 2. Adjust the position on all weather guards and mount bars to achieve the best fit. 3. Tighten all nuts. Table 10. Weather Guard Mount Bar Components Description Item...
  • Page 32: Install The Collapsible Hopper Cloth

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 19. Mount Bar Schematic Diagram (WCX 1335) 4.13. Install the Collapsible Hopper Cloth Install the Hopper Shield 1. Install the hopper shield (3) onto the conveyor frame using 3/8" x 1" carriage bolts (1) and 3/8" locknuts (2).
  • Page 33 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Install the Hopper Cloth Frame 1. Slide the upper side frames (1) into the hopper cloth (2) (see Figure 21). Note Apply grease to frame pieces if required. Note Steps 2–4 will be performed later in the hopper cloth installation.
  • Page 34 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Note The textured side of the flashings should be facing down. 2. Lay the side flashings (2) on the hopper while ensuring they are flush with the edge of the main hopper frame and overlapping the front flashing.
  • Page 35 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 23. Installing the Hopper Springs and Shaft Brackets 3. Clip the hopper springs over the tabs on the hopper and shaft bracket (see Figure 24). 4. Fasten a 3/8" x 2-1/2" bolt (3), 3/8" washer (4), and 3/8" nut (5) on the shaft bracket such that the loop on the spring captures the bolt.
  • Page 36 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 24. Orientation of the Shaft Bracket for 1300 Series Conveyors Install the Hopper Cloth 1. Attach the side frames (1) to the shaft brackets (2) using 5/16" x 1" hex bolts (3) and 5/16" whiznuts (4).
  • Page 37: Install The Spout Hood

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Table 16 Components for Installing the Hopper Cloth onto the Conveyor (continued) Item Description 1/4" Flat Washer Lower Back Frame Trimlock Vinyl Screw Cap (not shown) Figure 25. Installing the Hopper Cloth onto the Conveyor 4.14.
  • Page 38: Assemble The Wheel Hub

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 26. Installing Spout Hood 4.15. Assemble the Wheel Hub 1. Remove any dirt or paint from the spindle of the axle (1) and hub (4). 2. Thoroughly pack the wheel bearings (3, 5) and cups with a good grade of bearing grease.
  • Page 39: Install The Wheels

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 27. Wheel Hub 4.16. Install the Wheels 1. Check if the pressure of tires matches the pressure indicated on the tire sidewall. 2. Mount the wheels (1) to the axle (2) using 1/2" x 1-3/4" wheel bolts (3) (see Figure 28).
  • Page 40: Assemble The Undercarriage

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 28. Attaching the Wheels to the Axle 4.17. Assemble the Undercarriage Ensure the wheels are mounted to the axle before beginning this procedure. 1. Fasten the lower reach arms (1) to the axle (2) using 7/16" x 1" bolts (3) and 7/16" locknuts (4). Refer to...
  • Page 41 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 29. Attaching Lower Reach Arms and Cross Member 4. Lift the spout end of the tube with a front end loader and a strong sling/chain or block and tackle. The height should be sufficient to clear undercarriage assembly.
  • Page 42 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Table 21. Lift Arm Components Item Description 5/8" x 1-1/2" Bolt 5/8" Locknuts Lift Arms Tube Clamp Bolt Location with Hydraulic Motor Drive Bolt Location with Electric Motor Drive Figure 30.
  • Page 43 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY e. Bolt the tubing cross brace supports together in the center where they cross with 7/16" x 1-1/4" bolts (14) and 7/16" locknuts (4). f. Once in position, tighten the bolts.
  • Page 44: Install The Tube Lift Cable

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4.18. Install the Tube Lift Cable 1. Wrap the cable (1) around the bottom side of the winch drum with three complete wraps around the drum when conveyor is in transport position (see Figure 32).
  • Page 45: Electric Motor Drive (Option A)

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 32. Installing the Tube Lift Cable Figure 33. Winch Drum and Lift Cable 4.19. Electric Motor Drive (Option A) Install the Motor Mount 1. Measure and mark 127 mm (5") from the inside of the angle ring on the spout tube, see Figure 2.
  • Page 46 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 3. Loosely secure motor mount bracket (1) and 10" hitch ring (2) onto the conveyor tube using six 7/16" x 1" bolts (3) and 7/16" locknuts (4). Note Orient the motor mount bracket precisely as shown in Figure 4.
  • Page 47 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 34. Motor Mount Bracket 127.00 mm 127.00 mm Figure 35. Motor Mount Install the Motor 1. Install the electric motor on the motor mount. Do not tighten at this time.
  • Page 48 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 2. Route the power cord from the motor toward the intake end through the brackets underneath the tube and out to the power source. Ensure cord does not interfere with operation of track shoe or cord damage will occur.
  • Page 49 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 36. Installing the Pulleys and Belt Recommended Pulley Size Conveyor Size Conveyor Pulley Motor Pulley Belt Speed (ft/min) 15" 4.0" All Models 15" 4.25" Speed is calculated using a 1725 rpm electric motor.
  • Page 50 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Table 26. Guard Mounts Item Description Upper Guard Mount Drive Guard Mount 1/2" x 1-1/4" Bolt 1/2" Locknut Figure 37. Attaching Guard Mounts 2. Assemble pulley shields (5, 6) and extension (7) using 1/4" x 1/2" bolts (8) and 1/4" whiznuts (9) (see Figure 38).
  • Page 51 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 38. Assembling Pulley Guard 3. Hold and center the pulley guard over the belt and pulley (see Figure 39). 4. Attach the pulley guard to the upper guard mount (1) using 1/4" x 1" bolts (10) and 1/4" whiznuts (9). Do not tighten.
  • Page 52: Hydraulic Drive (Option B)

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 39. Securing Pulley Guard 4.20. Hydraulic Drive (Option B) Install the Bearing Mount Plate 1. Remove the drive roller bearing bolts and replace with two 1/2" x 2-3/4" bolts (1) from the kit.
  • Page 53 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY Figure 40. Installing the Bearing Mount Plate Install the Hydraulic Motor and Guards 1. Slide the hydraulic motor assembly (1) onto the drive roller shaft. Ensure that the chain coupler is seated properly.
  • Page 54 4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR Figure 41. Installing Hydraulic Motor and Guards 5. Attach and secure hydraulic hoses to the motor. Note Hydraulic hoses and couplers are not included. Table 31. Recommended Hydraulic Hose Size...
  • Page 55: Decal Placement

    42. Ensure that each decal is centered on each side of the tube. 2. Place the Westfield decal (2) on both sides of the upper tube below the discharge end. Ensure that each decal is centered on each side of the tube.
  • Page 56: Install The Manual Container

    4. ASSEMBLY WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4.22. Install the Manual Container 1. Attach the manual holder bracket (1) to the lower reach tube using a 3/8" x 2-1/2" u-bolt (2), two 3/8" flat washers (3), and two 3/8" locknuts (4).
  • Page 57: Attach The Jack

    WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 4. ASSEMBLY 4.23. Attach the Jack 1. Insert the jack (1) into the jack stub (located on the conveyor hitch) (see Figure 44). 2. Secure the jack in place with the pin (2) provided.
  • Page 58: Specifications

    5. SPECIFICATIONS WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 5 5 . . S S p p e e c c i i f f i i c c a a t t i i o o n n s s...
  • Page 59 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 5. SPECIFICATIONS 30998 R1...
  • Page 60: Westfield Conveyor Warranty

    Company, or to our factory, with transportation charges prepaid. This warranty does not obligate Westfield Industries Ltd. to bear the cost of labor in replacing defective parts. Any defects must be reported to the Company before the end of the warranty period.
  • Page 61 WCX 1335 TOP-DRIVE CONVEYOR – PORTABLE GRAIN BELT CONVEYOR 6. WESTFIELD CONVEYOR WARRANTY 30998 R1...
  • Page 62 P.O. Box 39 Rosenort, Manitoba, R0G 1W0 Canada Phone: (866) 467-7207 (Canada & USA) or (204) 746–2396 Fax: (866) 768-4852 Website: www.grainaugers.com Email: sales@grainaugers.com ©Ag Growth International Inc. 2018 Printed in Canada If you have any comments or questions on this manual, or find an error, email us at comments@aggrowth.com. Please include the part number listed on the cover page in your message.
