- Page 1 TRAVEL-SMART AWNING SERIES » LYNX 240 « Model No . 12010322400000...
-
Page 2: Table Of Contents
WELCOME Thank you for purchasing this Westfield Outdoors awning. Please read these instructions for use fully and carefully before using your awning. Please observe the care and safety instructions. SUMMARY ASSEMBLY PARTS LIST GENERAL RECOMMENDATIONS AND USAGE THE AIR TUBES... -
Page 3: Assembly Parts List
Model No. 12010322400000 ASSEMBLY PARTS LIST 1.Clean repair area thoroughly 2.Press patch fiemly over puncture 3.Do not inflate for four(4)hours to allow repair to set arry Bag Storm roof Pole Pump & Safety TPU repair patch Pressure Valve x14/22 Guy rope Metal /Plastic Peg Elastic Ring Draft Skirt &... -
Page 4: General Recommendations And Usage
GENERAL RECOMMENDATIONS AND USAGE • We recommend the use of an additional groundsheet or covering to avoid any damage to your awning whilst fitting it to your caravan, motor home or vehicle. • Please familiarize yourself with the awning before you go on your first trip. We recommend a test set-up before your trip. -
Page 5: Inflating/Deflating
INFLATING/DEFLATING Inflation The included pump is equipped with an over pressure valve. This prevents you from overfilling the air tube. The ideal air pressure is 7 PSI (0.48 bar). To inflate your awning: • Ensure that the valves on the awning are screwed in correctly. •... -
Page 6: Replace An Air Tube
REPLACING A TPU AIR TUBE Replacing or Repairing an Air Tube Deflate the air tube fully. NEVER replace or repair a tube before deflating it fully. Break the plastic ties on the sleeve of the air tube and unzip the sleeve. Then remover the protective cover and air tube from inside the sleeve. -
Page 7: Pitching Instructions
PITCHING INSTRUCTIONS • If requested fit the draft skirt by sliding it into the lower rail on the bottom of your caravan, motorhome or vehicle. The wheel cover either slides into the rail on the wheel arch or uses the figure of eight tubing and connects to the top of the draft skirt. - Page 8 PITCHING INSTRUCTIONS • You are ready to inflate your awning. • Before you inflate your awning make sure you have read and understood the pump and inflation sections of this instruction. You must follow these instructions to ensure proper inflation of your awning. •...
- Page 9 PITCHING INSTRUCTIONS Storm Roof Pole Assemble the storm roof pole as shown in the diagrams above. Insert each pole in turn, into their pocket and extend into the opposite pocket. Do not over tension these poles. PITCHING INSTRUCTIONS（OPTIONAL） Rear Pole Kit •...
-
Page 10: General Care And Usage Instructions
GENERAL CARE AND USAGE INSTRUCTIONS Canvas Seams The main seams of this awning are taped to ensure water protection. These can become damaged over time but can be repaired and re-sealed by using seam sealer. For the best results, we recommend contacting your dealer to find out which products to use. - Page 12 Westfield Outdoors GmbH Siemesdyk 60 47807 Krefeld Germany Drawings in this manual are for illustration purposes only, actual product may vary. Manufacturer reserves the right to change any specification or features without prior notice. Should you have any questions about your product or experience any difficulties, please contact the retailer from which you purchased the product.
