Summary of Contents for Sigma X-treme AZ68
- Page 1 User Manual X-treme AZ68...
- Page 2 X-treme AZ68 We thank you for buying mobile phone . This manual includes description of main mobile phone functions. X-treme AZ68 The phone allows to use 2 SIM cards of GSM standard at Dual Standby mode, i.e., in standby mode there are 2 cards in the connection;...
- Page 3 Do not try to open the body of the phone. If the phone or any of the accessories are not working properly, contact your nearest authorized service center. Use only accessories and chargers, that is designed for this model. Do not use defected USB-cables or chargers. ...
- Page 4 Please do not put the mobile phone under direct sunlight. To avoid of getting heavy metals, acids, lye in water or soil, causing significant damage to the environment, utilize used battery according to the law. The legal liability arises in case of infraction about the utilization norms.
- Page 5 Phone 2 SIM (mini-SIM) GSM: 850/900/1800/1900 MHZ Messages Mob. GPRS Internet Bluetooth V3.0 Display 2.4”, colour LCD, 320*240 pix Supporting MIDI, AAC, MP3, WAV, JPG formats FM-radio 87,5-108,0 MHz (built-in antenna) Micro-SD till 32 Gb Battery Li-Ion, 1700 mAh Package includes: •...
- Page 6 Torch Receiver Left soft key (LSK) \ Call SIM2 Central key Call SIM1 MicroUSB / Audio compartment Cancel/End/Power...
- Page 7 Control keys Right soft key (RSK) Camera Speaker Battery cover Keys specification To dial the number. Press and hold keys 2-9 for speed dial of preset numbers. 0 key - Press and hold - Turn the flashlight on / off * key In idle mode, press * key, cyclically shows “*”, “＋”, ”P”, ”W”.
- Page 8 In idle mode, press right soft key to access Phonebook menu. Central Menu / OK.
- Page 9 Inserting SIM cards and memory card Unscrew screws and open the back cover. Insert SIM cards in proper device slots. Insert also micro-SD card, if required. Insert battery, controlling that battery contacts fit phone contacts. Be careful, broken card or batteries cards lead to device breakage cancelling warranty.
- Page 10 Conditional screen marks on phone Connection signal Battery charge indicator New message Missed call Silence profile activated Outdoor profile activated Meeting profile activated Alarm clock is active Bluetooth switched on GPRS Internet is active Power on\off the device To power on the device press and keep button «power» until activation of device display.
- Page 11 Device blocking occurs automatically (if auto-lock is on) or by pressing the Cancel key (if set in Settings). Unlocking - by turning the LSK and the "*" key. Calling To call - dial number on digital keyboard in local or international format, or choose number from phone contacts list, and press Call button .
- Page 12 Messaging: for sending SMS messages and reading incoming messages; Profiles: Configure audio profiles Games Camera. Separate menu for launch camera Tools: alarm clock, calendar, Internet browser, flashlight, calculator, files manager, Bluetooth, SIM menu Contacts The Contacts menu is your phone book, which contains contacts stored in the phone and on SIM cards.
- Page 13 Delete: delete the selected contact. Copy: Copy contact between phone and SIM card. It also has the ability to: View memory status and delete all contacts, make backups - export - or restore contacts - import - (only if there is a memory card) When backing up contacts in the root of the memory card, a system file named vcard.vcf is created.
- Page 14 Note! In this model, FM radio operates with a built-in antenna. To improve the reception quality, you may need to connect a wired headset as an antenna. The sound of the FM radio and audio player is transferred to the external speaker and wired headset.
- Page 15 Display: Background settings, display contrast, screen backlighting and keystrokes Security: Provides the ability to set up SIM card lock, lock the phone, auto-lock, and lock certain phone functions. This menu also contains the Blacklist menu. Connections: allows you to set up GPRS, specify a default data transfer card, set up an account for data transmission, choose a way to select a network-manual or automatic.
- Page 16 system for different phone usage conditions such as: outdoor, indoors, silence, and more. It is possible to edit the built-in settings. To do this, press Options and Settings. To activate the set of settings, you must select a profile in the menu and press the center button.
- Page 17 If problem is not solved, contact to Sigma mobile service center. Check whether battery is charged and whether problem continues after device reset. Try to restore factory settings through menu «Settings - phone – Default settings» (password by default – 1122) Problems with memory card mostly occurs in case of memory card breakage.
- Page 18 to change location, check level of connection signal, wipe phone to factory reset. Contact in service center. Low receiver volume: during conversation, press button «up» to increase volume. Set volume during conversation in profiles. Check signal of cellular connection. Passwords Requests to input following passwords may occur during activating and phone use : Phone locked password - 1122: request occurs during...
