  • Page 1 Operator's Manual CA10 ProBus Current Adapter...
  • Page 3 CA10 ProBus Current Adapter Operator's Manual November, 2018...
  • Page 4 Teledyne LeCroy documentation for their own internal educational purposes. Teledyne LeCroy is a trademark of Teledyne LeCroy, Inc. Other product or brand names are trademarks or requested trademarks of their respective holders. Information in this publication supersedes all earlier versions. Specifications are subject to change without notice.

  • Page 5: Table Of Contents

    Operator's Manual Contents Safety Introduction Standard Parts Compatibility Connecting the CA10 Using the Heat-Shrink Tubing Connecting the CA10 to the Transducer/Transformer Programming the CA10 Customizing the CA10 Resistive Termination Filter Components Opening the CA10 Case Cleaning Returning a Product for Service...

  • Page 6: Safety

    Precautions Use only as intended. The product is intended to be used only with the compatible Teledyne LeCroy instruments. Using the product and/or the equipment it is connected to in a manner other than specified may impair the protection mechanisms.

  • Page 7: Introduction

    Specific information about the input device is programmed into the CA10 so that when the device is connected to the instrument it will correct for the transducer/transformer gain or attenuation and display the result in Ampere units.

  • Page 8: Connecting The Ca10

    We highly recommend using the included heat-shrink tubing to semi-permanently attach the CA10 to the transducer/transformer for which it has been programmed. However, the heat-shrink tubing is not required, and the CA10 will function perfectly without it. Cut the tubing into 1.5" length sleeves before using.
  • Page 9 Operator's Manual 3. Slide up the sleeve so that it is flush to the body of the CA10 and completely covers the connector. Apply heat until the wrap snugly encases the connection. 4. If desired, attach a removable label the front of the CA10 case and write the name and/or setup of the attached device.

  • Page 10: Programming The Ca10

    CA10 ProBus Current Adapter Programming the CA10 When the CA10 is first connected to the instrument, you will be asked if you want to program it. Select Yes to display the CA10 dialog: Enter all the device settings on the dialog, then select Save to Adapter.

  • Page 11: Customizing The Ca10

    R4, R13 and/or R14 terminating resistor be installed in the CA10 to provide a voltage output to the oscilloscope. It is the operator's responsibility to ensure that these resistors are suitably rated for the input current at J3 in the schematic below.

  • Page 12: Filter Components

    CA10 ProBus Current Adapter Filter Components The locations C7, C8 and L1 can be used to create a filter to remove higher frequency noise that might be present at a current transducer or transformer output. The specific components that might be installed depends on the desired frequency response as well as the instrument and transducer impedance.
  • Page 13 Operator's Manual...

  • Page 14: Opening The Ca10 Case

    CA10 ProBus Current Adapter Opening the CA10 Case To open the CA10 case: 1. Remove the two screws on the connector end of the adapter (shown at bottom of the image below). 2. Remove the front face and pull out the PCA board.

  • Page 15: Returning A Product For Service

    Return Material Authorization (RMA) code and instruct you where to ship the product. All products returned to the factory must have an RMA. Return shipments must be prepaid. Teledyne LeCroy cannot accept COD or Collect shipments. We recommend air-freighting. Insure the item you’re returning for at least the replacement cost.

  • Page 16: Certifications

    CA10 ProBus Current Adapter Certifications EMC Compliance EC Declaration of Conformity - EMC The product meets the intent of EC Directive 2004/108/EC for Electromagnetic Compatibility. Compliance was demonstrated to the following specifications as listed in the Official Journal of the European Communities:...

  • Page 17: Safety Compliance

    The product is subject to disposal and recycling regulations that vary by country and region. Many countries prohibit the disposal of waste electronic equipment in standard waste receptacles. For more information about proper disposal and recycling of your Teledyne LeCroy product, please visit teledynelecroy.com/recycle. Restriction of Hazardous Substances (RoHS)
  • Page 18 The product is warranted for normal use and operation, within specifications, for a period of one year from shipment. Teledyne LeCroy will either repair or, at our option, replace any product returned to one of our authorized service centers within this period.
