Designed for: artec 28, artec 510 and artec 510a.

Advertisement

AXW-3
Introducción
El soporte de pared AXW-3 está
diseñado para el producto: artec 28,
artec 510 y artec 510A.
Precauciones de Seguridad
Los AXW-3 han sido diseñados
para ser utilizados en vertical, cualquier
otra
posición
puede
provocar
problemas
de
seguridad
en
conjunto.
Los tacos suministrados son para
uso en paredes de
ladrillo, para
cualquier
otro
material
deberá
proveerse de los tacos adecuados.
D.A.S. Audio no se
respon-
sabilizará de usos no recomendados
de este soporte, ya sea la no
utilización de los tacos o tornillos
suministrados, o la sujeción de la caja
a superficies que no tengan suficiente
resistencia a la tracción, como son
escayola y yeso, por ejemplo.
Contacte
con
un
instalador
autorizado si tiene cualquier duda.
Garantía
Todos nuestros productos están
garantizados por un periodo de 24
meses desde la fecha de compra.
Las garantías sólo serán válidas si
son por un defecto de fabricación y
en
ningún
caso
por
un
incorrecto
del
producto.
reparación en garantía cubre la
reposición
de
las
partes
defectuosas. Otros cargos como
portes y seguros, son a cargo del
comprador en todos los casos. Para
solicitar reparación en garantía es
imprescindible que el producto no
haya sido previamente manipulado e
incluir una fotocopia de la factura de
compra.
D.A.S. AUDIO S.A.
C/ Islas Baleares, 24 - 46988 - Fuente del Jarro. Valencia - SPAIN - Tel. 96 134 05 25 - Tel. Intl. +34 96 134 08 60 - Fax +34 96 134 06 07

Introduction

AXW-3
The
wall
mounting
1.- Marcar en la pared los seis orificios
artec 28, artec
a realizar en la pared, ayudándose de
brackets is designed for:
510 and artec 510A.
la plantilla situada en el reverso de esta
hoja.
2.- Realizar los orificios y colocar los

Safety Precautions

tacos.
3.- Colocar en posición el soporte y
The AXW-3 bracket has been
atornillar 5 de los 6 tornillos de cabeza
designed to be wall mounted in the
hexagonal.
vertical
position
only.
Any
other
4.- Asegurar un extremo del cable al
el
position is a safety hazard.
soporte utilizando el sexto de los
Wall plugs provided are to be
tornillos de cabeza hexagonal.
used in brick walls only. For other wall
5.- Atornillar la pieza (F) a la caja
materials, source the suitable wall plug
utilizando 4 tornillos cilindricos con
before use.
hexágono
D.A.S. Audio is not responsible
Grower.
for use other than the recommended.
6.- Colgar la caja del soporte utilizando
Use only the screws and wall plugs
la pieza (F) a modo de bayoneta.
supplied on surfaces that will provide
7.- Direccionar la caja en la posición
sufficient support. Do not use on
adecuada y proceder a asegurarla con
surfaces such as plaster, and gypsum.
los dos espárragos (D) y el apriete del
Contact a licensed rigger if there
tornillo (E).
is any doubt.
8.- Asegurar el extremo libre de el
cable al orificio de la pieza (F)
impidiendo la extracción accidental de
la caja.

Warranty

All
D.A .S.
products
are
w a r r a n t i e d
a g a i n s t
a n y
manufacturing defect for a period
of 2 years from date of purchase.
The warranty
ex-cludes damage
uso
from incorrect or misuseuse of the
4x Tornillos M8x16 DIN 912
La
product. All warranty repairs must be
4x Tornillos M5x25 DIN 912
exclusively
undertaken
by
the
4x Arandelas M8 (grower) DIN 127B
factory or any of its authorized
4x Arandelas M5 (grower) DIN 127B
service centers. To claim a warranty
4x Arandelas M5 DIN 125
repair, do not open or intend to
1x Tornillo M5x6 DIN 7985
repair
the
product.
Return
the
1x Arandela M5 DIN 6798J
damaged unit, at shippers risk and
6x Tornillos ø6x40 DIN 571
freight
prepaid,
to
the
nearest
6x Tacos Nylon nº8
service center with a copy of the
1x Llave Allen nº4
purchase invoice.
1x Llave Allen nº6
Instrucciones de montaje

Mounting instructions

1.- Mark the 6 holes on the wall using
the template provided on this page.
2.- Drill the six holes and insert the wall
plugs.
3.- Set the bracket into position and
tighten 5 of the 6 hexagonal-headed
screws.
4.- Affix an end of the cable to the
bracket using the sixth hexagonal-
headed screw.
5.- Screw (F) to the enclosure using 4
hexagon socket head cap screws and
4 Grower (lock) was-hers.
6.- Lift the enclosure and slide it down
interior
y
4
arandelas
so that (F) fits into the bracket.
7.- Aim the enclosure as needed and
proceed to secure it by tightening
screws (D) with the suitable Allen (hex)
wrench and tighten screw (E).
8.- Affix the free end of the cable to the
hole in (F).
Contenido

Contents

4x M8x16 DIN 912 screws
4x M5x25 DIN 912 screws
4x M8 (grower) DIN 127B washers
4x M5 (grower) DIN 127B washers
4x M5 DIN 125 washers
1x Tornillo M5x6 DIN 7985 screw
1x Arandela M5 DIN 6798J washer
6x Tornillos ø6x40 DIN 571 screws
6x n.8 Nylon wall plugs
1x n.4 Allen wrench
1x n.6 Allen wrench
MANUAL DEL USUARIO / USER'S MANUAL
E
D
F
www.dasaudio.com
HI_AXW3_01
