Tektronix TriMode TDP7700 Series Technical Reference page 43

DC input resistance (, typical)
Low frequency input capacitance
(differential, typical)
Solder-in tips
Browser
Operating voltage window, typical
Solder-in tips
Browser
SMA adapter
Offset voltage range, typical
Solder-in tips
Browser
SMA adapter
Input range, typical
Solder-in tips
Browser
SMA adapter
TDP7700 Series TriMode Probes Technical Reference
Tips/Adapters
P77C292MM
P77STFLXA, P77STCABL
P77BRWSR
0.4 pF
0.23 pF @ 50 mil spacing
0.22 pF @ 200 mil spacing
±5.25 V
±10 V
±4 V
-4 V to +4 V
-10 V to +10 V
-4 V to +4 V
Single-ended
2.5 V
pp
Single-ended
6.0 V
pp
Single-ended
1.2 V
pp
Differential
100 Ω
100 kΩ
144 kΩ ± 20%
Differential
5.0 V
pp
Differential
12.0 V
pp
Differential
2.0 V
pp
Specifications
35
