Reach-in Configurations

Wall-to-Wall

INSTALLATION INSTRUCTIONS

Tools needed: Tape measure, level, pencil, #2 Philips head screw driver or power drill with a 6" #2 Philips bit, power saw with

wood cutting blade, optional drill template, tube cutter, hacksaw

Parts required: Shelf, backwall channel, sidewall bracket, universal pole cup, shelf and rod angle brackets or shelf angle

brackets, closet rods, closet rod end caps, shelf trim, drywall fasteners [Easy anchors with #8x 1-1/4" flat head wood screws], stud

fasteners [4.5 x 60 mm wood screws], #6 x 5/8" flat head wood screws [for securing components to the shelf or shelf to hardware]

and self-tapping screws [to secure the closet rod to the universal pole cup]. Make sure you have the right sizes and matching right or

left shelf end caps as applicable.

Replacement Warranty: You must follow the manufacturer's instructions supplied by ClosetMaid to ensure eligibility for the

For video instructions: Visit www.closetmaidpro.com/ExpressShelf.

Table of Contents

Need help?

Do you have a question about the ExpressShelf and is the answer not in the manual?

Page 1 [to secure the closet rod to the universal pole cup]. Make sure you have the right sizes and matching right or left shelf end caps as applicable. Replacement Warranty: You must follow the manufacturer’s instructions supplied by ClosetMaid to ensure eligibility for the replacement warranty.
Page 2 Installation Steps STEP 1 - Install the Backwall Channel Cut the backwall channel to the same width as the back wall measured from corner to corner. Determine and mark the desired height for each shelf. • For stud mount, level the backwall channel and fasten with screws directly to studs every 16"...
