P rem i u m Woo d Co l l e ct ion

Reach-in Configurations -

Wall-to-Wall

INSTALLATION INSTRUCTIONS

Tools needed: Tape measure, level, pencil, #2 Philips head screw driver or power drill with a 6" #2 Philips bit,

Midre saw with

12" dia. x 1/8" thick

wood-cutting blade (for cutting shelf), optional drill template, tube cutter, hacksaw (for cutting closet rod)

Parts required: Shelf, backwall channel, sidewall bracket, universal pole cup, shelf and rod angle brackets or shelf angle

brackets, closet rods, closet rod end caps, shelf trim, drywall fasteners [Easy anchors with #8 x 1-1/4" flat head wood screws], stud

fasteners [4.5 x 60 mm wood screws], #6 x 5/8" flat head wood screws [for securing components to the shelf or shelf to hardware]

and self-tapping screws [to secure the closet rod to the universal pole cup]. Make sure you have the right sizes and universal end

caps as applicable.

Replacement Warranty: You must follow the manufacturer's instructions supplied by ClosetMaid to ensure eligibility for the

For video instructions: Visit www.closetmaidpro.com/ExpressShelf.

Table of Contents

Need help?

Do you have a question about the ExpressShelf and is the answer not in the manual?

Page 1 [to secure the closet rod to the universal pole cup]. Make sure you have the right sizes and universal end caps as applicable. Replacement Warranty: You must follow the manufacturer’s instructions supplied by ClosetMaid to ensure eligibility for the replacement warranty.
Page 2 PLEASE NOTE: A 3/32 in. hole is required to be pre-drilled into the ventilated wood shelf in every circumstance where screws are installed through the ExpressShelf Hardware and into the ventilated wood shelf. STEP 1 - Measure STEP 4 - Measure and Cut Shelf to Size Locate your cut on the shelf.
