uAvionix pingEFB ADS-B Quick Start Manual

Receives traffic information (ads-b/ads-r and tis-b) on both uat (978 mhz) and 1090 es (1090 mhz)
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
uAvionix Brand Logo Specs (REV D) 20160329
Logo font: Helvetica Neue LT Std 75 Bold
= PANTONE P 48-16 C (OR EQUIVALENT)
= PANTONE P 179-11 C (OR EQUIVALENT)
uAvionix pingEFB ADS-B Receiver
Q U I C K S T A R T G U I D E

Advertisement

loading
Need help?

Need help?

Do you have a question about the pingEFB ADS-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for uAvionix pingEFB ADS-B

Summary of Contents for uAvionix pingEFB ADS-B

  • Page 1 Brand Logo Specs (REV D) 20160329 Logo font: Helvetica Neue LT Std 75 Bold = PANTONE P 48-16 C (OR EQUIVALENT) = PANTONE P 179-11 C (OR EQUIVALENT) uAvionix pingEFB ADS-B Receiver Q U I C K S T A R T G U I D E...

  • Page 2: Specifications

    Supported Interface Micro-USB safety • The pingEFB ADS-B Receiver adds an additional layer of situational awareness to aircraft operations in the airspace. Accordingly, pilots must remain vigilant of surrounding air traffic at all times during flight to ensure safe operation.
  • Page 3 Quick Start Guide uAvionix pingEFB receives traffic information (ADS-B/ADS-R and TIS-B) on both UAT (978 MHz) and 1090 ES (1090 MHz). When in proximity to a ground station it also receives flight information (FIS-B) and additional traffic (TIS-B) over UAT.
  • Page 4 Connect Connect pingEFB to your Stratux hardware using a Micro- USB cable or a Micro-USB OTG adapter. pingEFB should be mounted with the antenna oriented vertically.
  • Page 5 Configure Connect your EFB device to the Stratux Wi-Fi Network and enable Ping ADS-B on the settings page. Open a web browser. Access the configuration page by entering the IP address for your Stratux configuration. The default is http://192.168.10.1 From the Menu select Settings...
  • Page 6 Launch Launch your Stratux compatible Electronic Flight Bag (EFB) application.
  • Page 7 Track Configure your EFB as necessary receive Stratux data. In most applications it will be automatically detected. ADS-B traffic and flight information should begin streaming to the application when in range. Typical iOS Electronic Flight Bag is shown below with traffic.
  • Page 8 ADS-B ground station reception will usually not be available until in-flight. Ground stations provide additional traffic and flight information (FIS-B) data. pingEFB requires Stratux v1.1 or later. The latest Stratux builds and support are available at: http://stratux.me www.uavionix.com...
