T-1000 QUICK START GUIDE
This quick start guide explains basic instructions on how to unbox and set up the T-1000 UV 3D printer. For more
information, please refer to T-1000 manual v1.8, available for download at www.g3dsys.com.
1
2
3
4
5
6
7
8
9
10
11
Build Plate Lock Screw
1
Build Plate
2
Acme Thread
3
Vat
4
Vat Lock Screw
5
Build Plate
* Shake the resin bottle before each use.
COMPONENTS
Calibration Lever
6
Servo Panel
7
USB Port
8
Ethernet Port
9
WiFi Reset
10
ACCESSORIES CHECKLIST
Clippers
*Resin
12
13
14
15
Scraper
Power Button
11
Lifting Handle
12
Main Switch
13
Fuse Holder
14
Power Cable
15
Vat
Advertisement
Related Manuals for G3D T-1000
Summary of Contents for G3D T-1000
- Page 1 T-1000 QUICK START GUIDE This quick start guide explains basic instructions on how to unbox and set up the T-1000 UV 3D printer. For more information, please refer to T-1000 manual v1.8, available for download at www.g3dsys.com. COMPONENTS Build Plate Lock Screw...
- Page 2 REMOVE THE ACCESSORY BOX TILT THE T-1000 BOX Slightly tilt the T-1000 box. Make sure to hold or lean the T-1000 box against a wall to prevent from falling. TRIM THE BOTTOM TAPED EDGES OPEN THE BOTTOM FLAPS Unfold the bottom flaps of the T-1000 box.
- Page 3 UNBOXING AND SETTING UP THE T-1000 REMOVE THE ACCESSORY FOAM SUPPORT LIFT THE T-1000 BOX Remove the plastic cover of the T-1000. LIFT THE T-1000 UV 3D PRINTER Printer can be heavy for one person. 2 person lift is recommended. Move up the lifting handles of the printer to separate the printer from the bottom foam support.
- Page 4 SPOUT and the spout should be located at the back right position of T-1000. See T-1000 Vat Guide for details, attached on the vat. Do not remove the FEP film on the vat. It is for the vat’s protection, manufacturer's warranty will be void if it's removed.
