FrontRow ISM-02 User Manual page 2

Charging the ISM-02 Pass-around Microphone
Charge your microphone in one of four ways:
• IMC-01 universal microphone charger (optional)
• USB cable connected to one of your Juno Tower or Smart
Receiver charge jacks
• USB cable connected to your computer's USB jack *
• USB cable connected to a USB to AC power adapter
* NOTE - When charging from a computer USB port:
If using a laptop on battery power and the battery is low, the ISM-02 microphone
will not charge. It is recommended that you always have your laptop plugged in to
a power source when attempting to charge or program your microphone.
The ISM-02 microphone will not charge from a low-power USB jack. If you are
having trouble charging from a USB jack on a computer that is plugged in to a
power source, try using a different USB jack on your computer.
The ISM-02 microphone will not charge unless you have first installed the software
drivers as part of the FrontRow Microphone Settings software application. To
download the application, visit gofrontrow.com.
If your microphone will not charge from one of the Tower or Smart Receiver charge
jacks, and your Tower or Smart Receiver is connected to a computer via a USB
cable, disconnect the Tower or Smart Receiver from the computer to charge.
IMPORTANT! To maintain proper charging when using the
IMC-02 universal microphone charger, occasionaly clean the charge
contacts on the bottom of the microphone using a cotton swab dipped in
rubbing alcohol.
IMPORTANT! To ensure top performance and avoid equipment damage,
batteries should be charged at room temperature.
IMPORTANT! To ensure top performance and avoid equipment damage,
FrontRow recommends replacing rechargeable Li-ion batteries every three
years.
IMPORTANT! Store the battery properly if it will be unused for a period
of more than 2 weeks.
1. Charge the battery in the microphone for at least 2 hours.
2. Remove battery from microphone, place it in its own bag or envelope
and store in a cool dry place.
3. Recharge battery before next use.
Naming the ISM-02 Pass-around microphone
Your Pass-around microphone includes a location for adding a
name or room number for easy identification.
1. Remove the battery door using the supplied Philips head
screwdriver (Fig 4)
2. Slide the clear window out of the
battery door
3. Write the name of the micro-
phone on a blank that came
with your microphone
4. Place the name in the battery door
5. Slide the clear window back in
to the battery door
6. Replace the battery door and
tighten the screw
Customizing the microphone channels
You can customize channels* and other features of your
microphone using the FrontRow Microphone Settings
software application (free download from gofrontrow.com)
1. Connect the microphone to your computer with the FrontRow
Microphone Settings software application installed.
2. Open the FrontRow Microphone Settings software application.
3. Click on the Channel Assignments button.
4. Using the dropdown choices on the right, assign the desired
channels to the switch positions and click OK.
* The ISM-02 Pass-around microphone is set with switch position 1 set to channel A
and switch position 2 set to channel B. If you have the Channel Expansion module
installed in your Juno Tower or Smart Receiver, or if you are using the microphone
with another FrontRow product (Pro Digital, Lasso or Symbio), you must program the
switch positions so that your microphone transmits on the appropriate channels for
your receiver. See the channel programming guide in your Juno or Smart Receiver
User Guide for more details.
clear window
