FrontRow ELEVATE Quick Start

Teacher Microphone Features
Battery Signal
Indicator Indicator
Microphone
PrivaSee
Sensors
Alert Buttons
Volume Up
Mute /
Unmute
Volume Down
Action buttons
FRONT
USB Charge
Charge Contacts
BOTTOM
Microphone Setup
You must register (pair) microphones
before first use.
1. Charge Microphones - Place mics in
the charger until Battery LED is slowly
pulsing green.
2. Activate Base Station - Press the
Mic Registration button on the
ELEVATE Base Station (or remotely
via the CM900 Web Page). The
ClassLight will flash green.
3. Activate Mic
• Remove mic from charger, and wait
until it wakes up (8 seconds then
double-beep)
• Press the Mute button for 4 seconds
until you hear a triple-beep, then let
go. Both LEDs will flash green.
4. Ready! - Registration takes a few
seconds. When complete, the
ClassLight will stop flashing and the
mic will beep again. The mic is now
ready to use.
5. Repeat steps 2-4 for additional mics,
or when moving a mic to another room.
Microphone Tips
Charge microphones completely before first use.
There is no ON/OFF button for the ezRoom system or the microphones. They will "wake up" when they are picked up and "go to sleep" when not in use.
Charge microphones every night by placing them in the charging cradle or via USB cable.
The Action! and Bravo! Mics can be handheld, worn as pendant microphones, or clipped to a belt. If clipped to a belt, headset or lapel mic must be used.
Microphone volume should be set so it is audible just above the back-ground noise. If the teacher can hear themselves, it is probably too loud.
Battery Door
Alert
Button
3.5mm
Audio
Input or
Headworn
BACK LEFT SIDE
mic
1
2
3
4
SEC
ELEVATE
Student Microphone Features
Battery Signal
Indicator Indicator
Microphone
PrivaSee
Sensors
Mute /
Unmute
FRONT
USB Charge
Charge Contacts
BOTTOM
Status Indicators
Signal Status
Green = Unmuted
Amber = Muted
Amber (slow pulse) = Not connected
Amber (short flash) = Out of range
Battery Status
Green (slow pulse) = Fully charged
Green
= Charging
Red = Low battery
Charging
OR
NOTE: The mic will take a few seconds to wake up from charging.
Microphones
™
Quick Start
Battery Door
3.5mm
Audio
Input or
Headworn
mic
BACK LEFT SIDE
Action! Teacher Mic
Battery
Signal
LED
LED
Bravo! Student Mic
Signal
Battery
LED
LED
