5/15 Starting IRMA MATRIX on the PC via Ethernet
released
2

Preparation

2.1

Equipment required

• PC with Windows XP operating system or higher
• IRMA-MATRIX sensor(s)
• Service software programs for IRMA MATRIX sensors
Can be downloaded from www.irisgmbh.de: in the following variants:
What is required for connecting an IRMA MATRIX sensor to the PC:
1. 24 V power block M12 with M12 connecting cable: M12 connector (f, 5 poles, A coded).
2. The following sensor-connector combinations can be used for servicing IRMA MATRIX
3. Commercial Ethernet switch with several RJ45 or M12 slots.
4. M12/RJ45 adapter cable KQ-M12CAT5-RJ45-01-xm (accessory)
All cables and components used here are described in detail in the "M12 components for
Ethernet installations" catalogue.
Rev. 1.2 2016-02
• DIST500-Configuration (for sensor configuration)
• DIST500-Visualization (visualizes the measuring characteristics of a sensor)
• IRMA TestRide, IRMA MATRIX (for signal recording on test rides)
The power block is available as an accessory.
sensors via Ethernet:
• Type sCON-S-CAN-ETH-23-Kq-x-y with interfaces CAN, Ethernet for MATRIX
Figure
sensors (see also
• Type sCON-S-ETH-22-Kq-x-y with Ethernet interface for MATRIX sensors (see
Figure 5, p. 12)
M12 connector (male, 4 poles, D coded) to RJ45 connector (male) for PC connection
x = 2 m/10 m.
4, page 11).
