MORryde STP54-011 Pre-Installation Instructions

QUICK CONNECT STEP
PRE-INSTALLATION INSTRUCTIONS
Will the Quick Connect Step work for your RV?
MOUNTING SPACE
1
Measure the space between
the bottom of the threshold
and the bottom of the skirt.
A minimum distance of 1.75"
is required to attach the steps.
1.75"
NOTE : The steps will not work for
doors with trim under the threshold.
If you have met the requirements above, use the dimensions from Step 3 to locate your
part number in the fit chart below.
FIT CHART
PART
NUMBER
2 STEP
STP54-011
3 STEP
STP54-010
4 STEP
STP54-012
Please review the steps below.
INTERNAL FRAMING
2
The brackets require
structural reinforcement
behind the skirt metal
and below the threshold.
Units that do not have
any reinforcement for
the brackets will require
modification. For questions
contact our Parts Department
at 574-293-1581.
Skirt metal Threshold
STEP
HEIGHT
21.5" – 27.5"
27.5" – 36"
35.5" – 44"
Please contact us if you have any questions:
3
OPTIONAL HANDRAIL
574-293-1581 | www.MORryde.com
STEP HEIGHT
Measure from the top of
the threshold to the ground.
Refer to the Fit Chart below
for the corresponding Quick
Connect Step part number.
Threshold
Ground
3 STEP
HANDRAIL
STP214-029H
4 STEP
HANDRAIL
STP214-006H
