- Page 1 高清数字图传系统 Digital Video Transmission USER MANUAL DVLC系列 说明手册 无锡人人行拍网络科技有限公司 Wuxi R2TECK Co.,Ltd.
-
Page 2: Table Of Contents
Content 1. Easy way to start the device................2 2. Specification......................4 3. Introduction......................5 3.1 Disclaimer.....................5 3.2 Profile......................5 3.3 Intended usage....................5 3.4 Caution......................6 4. Product overview....................7 4.1 Brief introduction...................7 4.2 Standard spec....................7 5. Port definition......................9 5.1 Air module port....................9 5.1.1 Back side port..................9 5.1.2 Left side port..................11 5.1.3 Right side port..................11 5.1.4 Top side port..................12... -
Page 3: Easy Way To Start The Device
LINK light turn-on if the ground module connect to air module. HDMI monitor instruction (if installed the HDMI monitor). The monitor shows logo "R2TECK" after ground module connect to the power. After that, the monitor shows progress bar: Start-up / Selfcheck / Link. - Page 4 Disconnect the mobile with ground module wifi network. Wait ground module MOBILE light turn off. Repeat the above 4 steps. IOS App installation: In App store, search the key word “r2teck” and download. Module Module Figure1.1.3.1 Connection diagram...
-
Page 5: Specification
2. Specification Here list the detailed specification about DVLC, as shown in Table 2.1.1. Table 2.1.1 List of Parameters Performance Parameter 100mw ground distance ≥ 800m Communication Distance 800mw ground distance ≥ 3000m (double distance in air) (outdoor, no obstruction) If change to the wide angel directional patch antenna, the distance will be double. -
Page 6: Introduction
3.1 Disclaimer Thanks for purchasing the DVLC from Wuxi R2TECK. Everyone need to read and understand this disclaimer before using the DVLC. You are supposed to be accepted the disclaimer once the product is started to use. Please comply with the installation and using process indicated in this use manual. -
Page 7: Caution
DVLC should not work when it is wet. Have to make sure it is dry when you use it. It should be dried immediately at a ventilated place in case of accidentally wet. -
Page 8: Product Overview
4. Product overview 4.1 Brief introduction DVLC is the 1080p full-HD Digital Video transmission system which including air part and ground part, it transmit the video, image and more information by the wireless communication mode. DVLC is perfect for all fields video transmission because of the light weight, low power, long distance, low latency. - Page 9 4.2.2 Air module cable Air module power cable × 1 (standard) Air module power cable 12V 4.2.3 Ground module cable Power adapter × 1 (optional) Vehicle power 12V-DC for ground module HDMI cable × 1 (optional) Monitor HDMI cable Monitor × 1 (optional) For video receive and monitor Ground module tripod ×...
-
Page 10: Port Definition
5. Port definition 5.1 Air module port 5.1.1 Back side port REC CAM LINK POWER BIND FREQ-SW STOP/REC TF-CARD Figure 5.1.1.1 schematic diagram of back side port [1]: REC light, mp4 video recording status light Light status Description Operation The recording function is on and Turn-on the recording status is normal. - Page 11 [3]: LINK light, Indicate the wireless connection status with the ground module. Light status Description Operation The wireless module is connected to Turn-on the ground module. 1. Please wait for connecting; 2. Make sure the air module is connected the power; Turn-off The wireless module is not connected 3.
-
Page 12: Left Side Port
5.1.2 Left side port Figure 5.1.2.1 Schematic diagram of left side port [1]: MIPI camera port, Connect with MIPI camera, and get video data of the camera via this port. [2]: OSD port, When it is necessary to display the OSD information of the flight control system, connect to the data line port of the flight control system for reading OSD information. -
Page 13: Top Side Port
5.1.4 Top side port Figure 5.1.4.1 Schematic diagram of top side port [1]: 1080p /720p toggle switch, Toggle left to 1080p and right to 720p. 5.2 Ground module port 5.2.1 Bottom side port DC-12V 2S-3S BATTERY Figure 5.2.1.1 schematic diagram of bottom side port [1]: Battery port, For connect with 2S/3S battery. -
Page 14: Ground Module Port
5.2.2 Left side port Figure 5.2.1.1 schematic diagram of left side port [1]: FREQ-SW button, For switch frequency. Press the button more than 5 seconds, 4 lights (HDMI, LINK, OSD, WORK) are all turn-off, release the key, 4 lights flash as 0.5Hz frequency, and then 4 lights back to normal state, that means the factory setting was restored, and the factory setting was restored successfully. -
Page 15: Right Side Port
[5]: HDMI light, For monitor the camera status. Light status Description Operation Turn-on Camera connect well. Check whether the monitor is Turn-off Camera does not connect. connected correctly. [6]: MOBILE light, For monitor the status of connect with the mobile device (iPhone、iPad). -
Page 16: Front Side Port
5.2.4 Front side port Figure 5.2.4.1 schematic diagram of front side port [1]: Air vent, Pay attention to not cover the air vent. -
Page 17: Installation
6. Installation 6.1 Air module installation 6.1.1 Antenna installation （1）Take out two pcs air module antenna. （2）Install them on the air module antenna holes, when you hear a clicking sound indicates completion of installation. Attention: For better transmit result, please make sure the antenna be away from the metal and carbon fiber frame, avoid being blocked by the main body of the aircraft or batteries, antenna should be vertical to the ground. -
Page 18: Ground Module Installation
Currently, only IOS devices are supported, and the system version is required to be IOS8.0 or above. Android devices will open later. IOS App installation: In App store, search the key word “r2teck” and download. (* Please note: IOS users recommend that customers use iPhone for monitoring. -
Page 19: Bind And Frequency Switch
When you plan to do bind, pls put air module and ground module close, and ensure there is no other R2TECK system work nearby.（3） All buttons on the air module and ground module not work in 30 seconds since system power on. It means if you want do bind operation you must wait at least 30 seconds after system power on. -
Page 20: App Instruction
8. APP instruction 8.1 OSD setting Click OSD button, select "Turn on" or "Turn off", match to the "Display" or "Not display". Figure 8.1.1 schematic diagram of OSD setting of APP software 8.2 Power setting Click "setting" button to adjust the power, if click 100mw, then the video top right corner shows "PW: 100 OK", means output power setting is succeed. -
Page 21: Troubles Solution
9. Troubles solution Below is the device maintenances about DVLC, to help the users whom don't have professional testing device and technology to solve the simply troubles. 9.1 Trouble symptoms / diagnosis / solution Table 9.1.1 Trouble diagnosis and solution... -
Page 22: Appendix
10. Appendix 10.1 Monitor OSD content Beside the video, on the top side and bottom side of the monitor display the OSD data. SP: RF signal intensity VOLT: Voltage of air module PW: Transmitting power FREQ: Current frequency H: Hight of air module Lat: Latitude of air module Lng: Longitude of air module D: The actual flight distance of the drone (unit: m) -
Page 23: Contact Info
Thanks for purchasing our device again. If you have any suggestion or need technical support, please visit our website or send us the email, also welcome to call us. Contact info: Company name: Wuxi R2TECK Co., Ltd Address：Room307,Building of Cetus,Wuxi software park,111th Linghu avenue,new district ,Wuxi city,Jiangsu Province P.C.：214000 Tel：0510-81012344... - Page 24 Tel：0510-81012344 Web：http://www.gor2teck.com...
