OPERATING INSTRUCTIONS AND REPLACEMENT PARTS
models: mP-2300enB and mP-2300ecy
WArninG
this manual must be read carefully and followed by all persons who have or will have the responsibility
for using or servicing this equipment. this equipment will perform as designed only if used according
to the instructions. otherwise it could fail to perform as designed, causing personal injury or death.
Air SyStemS internAtionAl, inc.
829 Juniper Crescent, Chesapeake, Va, 23320
Telephone (757) 424-3967
Toll Free 1-800-866-8100
Fax No. (757) 424-5348
www.airsystems.com.
e-mail: sales@airsystems.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AIR SYSTEMS MP-2300E
Summary of Contents for AIR SYSTEMS MP-2300E
- Page 1 Air SyStemS internAtionAl, inc. 829 Juniper Crescent, Chesapeake, Va, 23320...
- Page 2 Specifications Dimensions 48”H x 25”W x 31”D Weight (w/o cylinders) 120 lbs. Frame Powder Coated Steel Cylinder Straps Four Adjustable Nylon Straps 5000 PSI Rated Thermo-Plastic Hose with a Whip Assemblies 4:1 Safety Factor Check Valves Stainless Steel, 1 per Whip Assembly Low Pressure Whistle Set @ approximately 500 PSI 5500 PSI Max.
- Page 3 Set-up/operation CGA-346/347 HAND-TIGHT BLEEDER VALVE LOW PRESSURE WHISTLE PRESSURE REGULATOR RESPIRATOR CONNECTIONS SteP 1) Place cylinders on cart and secure by tightening straps at the buckle. Mate the hook and loop sections to prevent slipping. SteP 2) Install the CGA-346/347 universal hand-tight nuts to the cylinder valves and tighten. Close the bleeder valves by turning knobs clockwise.
- Page 4 low Pressure Alarm test LOW PRESSURE WHISTLE INLET PRESSURE GAUGE PRESSURE REGULATOR RESPIRATOR CONNECTIONS SteP 1) Open one cylinder valve. SteP 2) Set the required outlet pressure by turning the regulator knob clockwise to increase pressure or coun- terclockwise to decrease. SteP 3) Close the cylinder valve by turning the knob fully clockwise.
- Page 5 replacement Parts item # DeScriPtion PArt # ASME RELIEF VALVE PRESET @ 125 PSI VR4125BR HANSEN COUPLING QDH3SL4M SCHRADER COUPLING QDSSL4M HANSEN DUST CAP QDH3DCAP SCHRADER DUST CAP QDSDCAP OUTLET PRESSURE GAUGE GA20160B PRESSURE REGULATOR, NO GAUGES REG-5000NG INLET PRESSURE GAUGE GA2075KB CHECK VALVE VC4SMMSS...
- Page 6 notes:...
- Page 7 Air Systems’ manufactured equipment is warranted to the original user against defects in workmanship or materials under normal use for one year from the date of purchase. Any part which is determined by Air Systems to be defective in mate- rial or workmanship will be, as the exclusive remedy, repaired or replaced at Air Systems’...
- Page 8 Rev. 3 April 2018 Air SyStemS internAtionAl, inc. 829 Juniper Crescent, Chesapeake, Va, 23320 Telephone (757) 424-3967 Toll Free 1-800-866-8100 Fax No. (757) 424-5348 http://www.airsystems.com e-mail: sales@airsystems.com Printed in the U.S.A. ©Copyright Air Systems International, Inc. 2018 All Rights Reserved...
