OPERATING INSTRUCTIONS AND REPLACEMENT PARTS
Transporter™
Breathing
By Air Systems International
MODEL: BAT-2B
PATENT PENDING
WArninG
This manual must be read carefully and followed by all persons who have or will have the responsibility
for using or servicing this equipment. This equipment will perform as designed only if used according
to the instructions. Otherwise it could fail to perform as designed, causing personal injury or death.
Air SySTEMS inTErnATiOnAL, inc.
829 Juniper Crescent, Chesapeake, Va, 23320
Telephone (757) 424-3967
Toll Free 1-800-866-8100
Fax No. (757) 424-5348
www.airsystems.com.
e-mail: sales@airsystems.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AIR SYSTEMS Breathing Transporter BAT-2B
Summary of Contents for AIR SYSTEMS Breathing Transporter BAT-2B
- Page 1 OPERATING INSTRUCTIONS AND REPLACEMENT PARTS Transporter™ Breathing By Air Systems International MODEL: BAT-2B PATENT PENDING WArninG This manual must be read carefully and followed by all persons who have or will have the responsibility for using or servicing this equipment. This equipment will perform as designed only if used according to the instructions.
- Page 2 SPEciFicATiOnS DIMENSIONS (IN VERTICAL POSITION) 67”H X 34.75”W X 26”D WEIGHT WITHOUT CYLINDERS 265 LBS. MAX. INLET PRESSURE 5000 PSI MAX. OUTLET PRESSURE 125 PSI RELIEF VALVE 125 PSI ASME PRESET RESPIRATOR CONNECTIONS LOW PRESSURE ALARM WHISTLE SET @ 500 PSI 1/4”...
- Page 3 LOW PrESSUrE ALArM TEST STEP 1) Open one cylinder valve. STEP 2) Set the required outlet pressure by turning the regulator knob clockwise to increase pressure or counterclockwise to decrease. STEP 3) Close the cylinder valve by turning the knob fully clockwise. STEP 4) Partially engage a plug into one of the respirator connections while viewing the inlet pressure gauge.
-
Page 4: Table Of Contents
cOnVErT FrOM 3 WHEELED PUSH cArT TO TOW POSiTiOn 3 WHEELED PUSH cArT STEP 1) STEP 2) Remove retaining pin. Remove tow tongue from receiver. STEP 3) STEP 4) Remove pull pin. Pull spring loaded pin. STEP 5) Index handle assembly as shown in picture on the right and replace pull pin. -
Page 5: Step
cOnVErT FrOM 3 WHEELED PUSH cArT TO TOW POSiTiOn STEP 6) STEP 7) Lay cart down. Pull safety chains out of tubes. Install tow tongue into receiver with wheel up. STEP 8) STEP 9) Replace hitch pin and install safety pin thru hitch Couple to tow vehicle and attach safety chains. -
Page 6: Step
TrAnSPOrT OPTiOnS FOrKLiFT 3 WHEELED WAGOn... -
Page 7: Step
TrAnSPOrT OPTiOnS 3 WHEELED PUSH cArT TOW POSiTiOn... -
Page 8: Step
rEPLAcEMEnT PArTS... -
Page 9: Step
rEPLAcEMEnT PArTS ITEM NO. DESCRIPTION PART NO. 10” PNEUMATIC SWIVEL CASTER HDWR101 4.80-12 BIAS TRAILER TIRE (1) AM30670 HANDLE GRIP HDWR308 SPRING PLUNGER HDWR156 CGA-347 WRENCH TIGHT NUT HPBR050 CGA-347 WRENCH TIGHT STEM HPBR049 HIGH PRESSURE WHIP ASSEMBLY, 1/4” MPT X 1/4” MPT PHA05036MS HIGH PRESSURE WHIP ASSEMBLY (INCL. - Page 10 nOTES:...
- Page 11 nOTES:...
- Page 12 Air Systems’ manufactured equipment is warranted to the original user against defects in workmanship or materials under normal use for one year from the date of purchase. Any part which is determined by Air Systems to be defective in mate- rial or workmanship will be, as the exclusive remedy, repaired or replaced at Air Systems’...
