Fanstel EzPro T56 User Manual

Using T56/T44 Amplified Telephones
Version 200906
Check to make sure the following items are included:
1. Telephone base 3. Wall mount bracket
2. Telephone handset 4. Handset cord, line cord
1. Visual ringer
2. Telephone keypad
3. ▲ - to increase receiver volume/tone amplification.
4. ▼ - to decrease receiver volume/tone amplification.
5. Retain Amplification LED – when the handset is off cradle,
LED light to indicate Retain Amplification switch is set to
On.
6. Retain Amplification switch – set to On to save
volume/tone amplification level for future calls.
7. Ringer switch
Desk Mounting
Plug one end of the 12 foot line cord into the jack labeled "Line" on
the bottom of phone and plug the other end into a wall jack.
The pre-assembled phone can be easily placed on a desk.
Wall Mounting
1. Insert the wall mount bracket into two holes labeled "WALL"
on the bottom of phone base.
2. Plug one end of the 7 inch line cord into the jack labeled
"Line" on the bottom of phone and
plug the other end into the jack on the
wall plate.
3. Slip the mounting holes (one on wall
mount bracket and one on rear edge
of base) over the wall plate posts and
firmly slide the unit into place.
.
Retain Amplification
Set the Retain Amplification switch to On (Retain Amplification
LED is lit when the handset is off cradle), the receiver volume
amplification level is saved automatically and used for all future
calls.
If the Retain Amplification switch is set to Off, receiver volume is
reset when you replace the handset in the handset cradle.
Warning: Possible loud receiver volume when the Retain
Amplification switch is set to On and the Retain Amplification
LED is lit.
Adjusting Handset Receiver Volume
To adjust the handset receiver volume during a phone call:
1. Press the ▲ button to increase the receiver volume
2. Press the ▼ button to decrease the receiver volume.
3. Stop adjustment when you can hear words most clearly.
Warning: Excessive handset receiver volume when the Retain
Amplification LED is lit.
Adjusting the Ringer Volume
The "RINGER" switch on the right side of the phone base controls
the volume. You can set the "RINGER" switch to "Hi" for a high
volume ring, "Low" for a low volume ring or "Off" to turn the ringer
off.
The Visual ringer flashes for all incoming calls regardless of the
ringer setting.
Making a Call
1. Pick up the Handset and listen for a dial tone.
2. Using the Keypad, dial the desired telephone number.
Receiving a Call
1. When you hear the phone ring, simply pick up the handset from
the handset cradle. .
2. When you are finished talking, replace the handset in the
handset cradle to end the call.
