- Page 1 M0009239 TYPE 5, 10, 15, 20 kVA Instruction Manual...
-
Page 2: Table Of Contents
Introduction Thank you for choosing the SANUPS A11J. SAVE THESE INSTRUCTIONS This manual contains important instructions for A11J that should be followed during installation and maintenance of the UPS* and batteries to protect the safety of the customer and the service technician . - Page 3 Notes about UPS Model This manual is for the following UPS Models. Confirm your UPS Model before using the UPS. When using a UPS with long backup times, for details on the extension battery, see the supplied instruction manual with the extension battery. Capacity Type UL Model...
-
Page 4: Before Use
Before Use § The following shows the procedures to use the UPS. Be sure to follow the procedures described in this instruction manual to ensure safe and proper use of the UPS. Check the safety precautions ⇒ pages 2 to 5 Check the operating precautions ⇒... -
Page 5: Safety Precautions
Safety Precautions § PRECAUTIONS (IMPORTANT SAFETY INSTRUCTIONS) This manual contains important instructions for operating and maintaining the A11J Series and the batteries to protect the safety of the customers and the service technician. Before installing, operating, performing maintenance or inspecting the UPS, be sure to read this manual and accompanying documents carefully to obtain a clear understanding of the information related to its operation, safety and important precautions. - Page 6 Safety Precautions 1. Relocation, Transportation and Moving Precautions CAUTION ！ Be careful to avoid falling or dropping the UPS during relocation, transportation, as bodily injury could result. Be careful to avoid back strain when handling the UPS. To avoid bodily injury or a malfunction caused by dropping the UPS, do not tilt the UPS more than 10 degrees to either side when moving it vertically.
- Page 7 Safety Precautions 4. Operating Precautions WARNING ！ Immediately shut the UPS off if it malfunctions, or if an unusual odor or noise is observed. Failure to do so may result in a fire. To avoid electric shock, do not open the cover of the UPS. Do not detach the cover for the option connections on the back of the UPS except when you use some options.
- Page 8 Safety Precautions 6. Radio Frequency Interference CAUTION ！ This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 9: For Proper Operation
Operating Precautions § § (1) Input Power Supply and Power Supply Capacity The following table shows the rated AC input power of this UPS. For the voltage and frequency variation ranges, see §12.4 “Specifications”. AC Input Input Input Branch UPS Name AC Input Voltage Rating Frequency Rating Capacity... -
Page 10: Usage Precautions
Operating Precautions § (1) Never short-circuit the output circuits. Doing so will cause the protective functions of the UPS to activate or the breaker to trip, preventing output. (2) Unsuitable load devices Do not connect laser printers, plain paper fax machines, copy machines, overhead projectors, vacuum cleaners or hair dryers to the UPS. -
Page 11: Checking Contents Of Package
Checking Contents of Package § After you open the package, check to make sure that it contains all of the following items. Does it contain the UPS and all accessories? Is the exterior of the UPS damaged or unusual? □ Check and place a mark in If any item is missing or unusual, contact your supplier or SANYO DENKI. -
Page 12: External Dimensions And Part Names
Part Names § § Inside Front Panel of UPS Unit ⑥ ⑤ UPS Front ① UPS Unit Front Panel (when LCD panel attached) ③ ④ ⑦ ② UPS Unit Back ⑧ ⑮ E XT.BAT TERY UPS Unit INPUT INPUT OUT PUT OUT PUT ⑩... -
Page 13: Lcd Panel
Part Names § ② UNINTERRUPTIBLE POWER SUPPLY ① ③ ⑤ ⑥ ⑩ ⑧ ⑦ ⑨ ④ Name Label Color Function When input power is normal. ① Input LED Green INPUT Blinking When input power is abnormal. ② Backup LED Green When the battery is operating. -
Page 14: Ups Unit Control Panel
Part Names § ④ ① ② ③ ⑤ Name Label Color Function When input power is normal. ① Input LED Green INPUT Blinking When input power is abnormal. When supplying power by inverter operation. ② Output LED Green OUTPUT Blinking When supplying power by bypass operation. ③... -
Page 15: External Interfaces
Part Names § ① ② ⑥ OP IF PDU IF Note PC I/F CARD I/F The PC interface connector and REMOTE/EPO SIGNAL I/F card interface connector cannot be used at the same time. OPTION CARD ③ ④ ⑤ Name Function When using SANYO DENKI’s power management software (option), connect the dedicated PC I/F ①... - Page 16 Part Names Name Function SIGNAL I/F Outputs status information of the UPS such as a power outage or voltage drop. ③ Contact signal External Transmission Signals and Shutdown Input Signals interface connector Pin No. and Status Signal Name Explanation when Operating This signal is output when there is a power outage 1-8: ON AC Input Error...
- Page 17 Part Names Name Function REMOTE/EPO Use these terminals for controlling the UPS with a non-voltage contact from an external ⑤ device. External control REMOTE/EPO Terminal Names External Appearance terminals 6 COM terminals 5 EPO 4 COM 3 Remote OFF 1 2 3 4 5 6 REMOTE terminals 2 COM...
-
Page 18: Installation And Wiring
Installation and Wiring § § Installation work should be performed by technically qualified personnel. When installing the UPS, carefully follow the instructions in this Instruction Manual. Improper installation can result in electric shock, bodily injury, and/or fire. Refer to the table in §5.1 for the weight of the UPS. In accordance with the instruction manual, install the UPS on a stable surface that can bear the weight. -
Page 19: Installing Ups
Installation and Wiring § Be sure to lock the casters on the bottom of the UPS, and adjust the level adjusters to fix the UPS so ！ that it is not tilted and does not wobble. If the UPS is not securely fixed, shock and vibration from, for example, an earthquake may cause the UPS to shift or fall, possibly resulting in bodily injury. -
Page 20: Connection Between Units
Installation and Wiring § The UPS units and the power distribution unit are connected with the cable as follows. If the cables were disconnected for transportation and installation, see the following figure, be sure to perform the wiring work properly. The figure shows four UPS units being connected. - Page 21 Installation and Wiring ⑤ Check that all of the cables are connected securely. ⑥ Attach the cable covers to all of the UPS units and the power distribution unit. ⑥Insert the tabs at the bottom, and secure the top in the two places on Insert the tabs.
-
Page 22: Wiring Inputs/Outputs
Installation and Wiring § Wiring work should be performed by technically qualified personnel. When wiring the UPS, carefully follow the instructions in this Instruction Manual. Incorrect wiring may result in electric shock and/or fire. There is the danger of electric shock, so wear insulated gloves as a preventive ！... - Page 23 Installation and Wiring ⑦ Connect the ground to the “ ” terminal of the INPUT terminal. Use D class grounding for the ground. ⑧ Connect the utility power supply to the “INPUT L and N” input terminals. ⑨ Connect the ground to the “ ”...
-
Page 24: Connecting Optional Equipment
The power can be managed with a computer by performing communication between the UPS and computer. For details, see the instruction manual of the power management software. Main Screen of SANUPS SOFTWARE Power Management Software Back of UPS EXT.BATTERY INPUT OUTPUT EXT.BATTERY... - Page 25 Installation and Wiring Blank page...
-
Page 26: Preparation Before Operation
Preparation Before Operation § § § § ① Set MAIN MCCB on all UPS units to “ON.” ① Set MAIN MCCB to “ON.” At this time, the state becomes as shown below depending on the setting state of the UPS. Proceed to the corresponding procedure depending on the state of the UPS. -
Page 27: Charging Ups
Green: Off Blinking ↓ Green: Blinking → Lit* Green: Off SANYO DENKI Red: Off SANUPS A11J The state of the LEDs of all UPS units After approx. 5 sec. becomes the same. - STANDBY - Vi=*** Fi=*** ① Set on all MAIN MCCB UPS units to “ON.”... -
Page 28: Power Outage Simulation Test
Green: Green: Off Red: Off Blinking Green: Off ↓ SANYO DENKI Green: Blinking→Lit SANUPS A11J Green: Off Red: Off After approx. 5 sec. - STANDBY - The state of the LEDs of all Vi=*** Fi=*** UPS units becomes the same. - Page 29 Preparation Before Operation ⑤ Set MAIN MCCB on any one UPS unit to “OFF.” Buzzer: Beep-beep, beep-beep, beep-beep… Green: Lit Green: Blinking Green: Lit Red: Off Green: Blinking - BATTERY Green: Lit **** Red: Off The state of the LEDs of all UPS units becomes the same.
-
Page 30: Operating Procedures
Green: Off Red: Off Green: Off Blinking ↓ Green: Blinking→Lit SANYO DENKI Green: Off SANUPS A11J Red: Off After approx. 5 sec. - STANDBY - The state of the LEDs of all UPS units becomes the same. Vi=*** Fi=*** ① Set... - Page 31 Operating Procedures ④ Check that the LCD display and LEDs are in the states shown in the diagram below. Green: Lit Green: Off Red: Off Green: Lit Green: Lit Green: Lit - ONLINE Red: Off **** The state of the LEDs of all UPS units becomes the same.
-
Page 32: Ups Shutdown
Operating Procedures § Follow the procedure below to shut down the UPS. Be sure to shut down the load devices prior to shutting down the UPS. ① Press any key on the LCD panel to display the screen. ② Press ③... -
Page 33: Operation Using Ups Unit Control Panel
Operating Procedures § You can use the UPS unit control panel on the right side of the front of the UPS unit to start up and shut down the UPS. The UPS unit control panel can be used to operate individual UPS units, so you can use it to shut down only a UPS unit that has malfunctioned. -
Page 34: Inspection And Maintenance
Inspection and Maintenance § Internal maintenance and inspection should be performed only by technically qualified personnel. Electric shock, injury, burning, fuming, or fire could otherwise result. Before beginning Inspection, shut down the UPS completely and remove the input power. ！ Failure to do so may result in an electric shock. -
Page 35: Routine Checks By Customer
Inspection and Maintenance § Be sure not to inspect the inside of the UPS. Doing so may result in an electric shock, burn, injury, smoke, or fire. Do not touch the fan on the back of the UPS when cleaning the UPS or anywhere ！... -
Page 36: Resetting Main Breaker
Inspection and Maintenance § If the total capacity of the load devices connected to the UPS exceeds the rated capacity of the UPS, the main breaker MAIN MCCB of the UPS unit control panel on the UPS unit trips. If a breaker is tripped, the power supply may stop. Follow the procedure below to reset the breaker. -
Page 37: Buzzer Sounds
Buzzer Sounds § T i p The buzzer sounds to indicate a UPS status error or change. Press to stop the buzzer. Check the sound pattern and see the following table for the countermeasures to take. Sound Pattern LCD Indication LED Status UPS Status Countermeasure... -
Page 38: Troubleshooting
Troubleshooting § Internal maintenance and inspection should be performed only by technically qualified personnel. Electric shock, injury, burning, fuming or fire could otherwise result. ！ Before beginning Inspection, shut down the UPS completely, and remove the input power. Failure to do so may result in an electric shock. CAUTION While the batteries are connected to the UPS, hazardous voltage is present. - Page 39 Troubleshooting UPS Status LCD Indication LED Status Countermeasure on the LCD panel or on the UPS unit control panel pressed Green INPUT Lit -STANDBY- accidenta1ly and set to “OFF”? Perform the correct procedure to set it to “ON.” Has the main breaker tripped? MAIN MCCB The breaker may have been tripped by an overload or short circuit.
- Page 40 Troubleshooting UPS Status LCD Indication LED Status Countermeasure LCD Panel Operation When “Auto” is set in §3.3 “Setting frequency” in the Manua l; is the UPS being on asynchronous operation? The UPS cannot switch to UPS power supply from the bypass power supply during asynchronous operation.
-
Page 41: Ups Characteristics
UPS Characteristics § § (1) When normal operation During normal operation, the UPS converts AC power from the utility power source into DC power through the rectifier, Utility and reconverts this DC power back into AC power through the Rectifier Inverter Output power... -
Page 42: Protective Functions
UPS Characteristics Indication of the marks in the table as folllows. § Lit LED: Blinking LED: The following table shows the functions and operations to protect the UPS. Buzzer alarms: ① to ⑥ Sending of transmission signal: ○ Indicators/Indications of Transfer Signal and Contact Signal Output Protective LCD Panel and UPS Unit Control Panel... -
Page 43: Specifications
UPS Characteristics § Item Standard or Performance Notes Type A11J502SA002U A11J103SA002U A11J153SA002U A11J203SA002U Model A11J502US002 A11J103US002 A11J153US002 A11J203US002 Output N units setting 5 kVA/4.5 kW 10 kVA/9 kW 15 kVA/13.5 kW 20 kVA/17 kW Selectable capacity Default: N units setting N+1 unit setting 5 kVA/4.5 kW 10 kVA/9kW... -
Page 44: Warranty
Warranty § Warranty for use in Japan: 1 year Warranty for use Overseas: 1 year Warranty for use in North America: 3 years ※ Valid only when the UPS is purchased from a vendor recognized by Sanyo Denki. ※ 1. In the above areas, this product is warranted for the specified periods against electrical failures due to materials or workmanship.
