M4+
OPERATING INSTRUCTIONS
Made in the Czech Republic
• The M4+ heavy duty hand tool is designed to install any
rivnut ranging in size from M3 ~ M12 as well as rivstuds
M4 ~ M8.
• The tool features a heavy duty body and comfortable
hand grips.
• This tool is ideal for small production work and
prototyping of larger sized rivet nuts.
• Weight: 2.4kgs.
• Length: 485mm.
• Kit contains M4+ tool ind M6, M8, M10 and M12 setups.
• Mandrel kits for M3, M4 & M5 along with all UNC and
UNF rivnuts are available as options.
• Mandrel kits for M4, M5, M6 & M8 rivstuds are
available as options.
