Dafra DRPB48 Operation Manual

DRPB48 Operation Manual
Pneumatic Blind Rivet Setting Tool - DRPB48
READ THIS MANUAL CAREFULLY BEFORE USING THE TOOL !
It is
against injuries.
- This tool should be used ONLY to set blind rivets within the TOOL'S CAPACITY. It MUST
NOT be used for other purposes, such as hammer, etc.
- This tool should be always operated with compressed air supply within the air pressure
range 0.5Mpa ~ 0.7Mpa.
- Always DISCONNECT the air supply from the tool before changing the tool parts, such as
jaws, etc.
- DO NOT use the tool in the environment described as below:
 fuel and combustion air.
 temperature rapidly rising.
 humidity, rain, water, storm and thunder, lightning.
- When the tool is suspended by the operation hook during use, be sure the tool will not fall.
- When using the tool, always carry protective goggles, protective gloves, safety helmet, and
other necessary protections. It is highly recommended for safety reasons.
- Only use genuine spare parts for maintenance and repairs.
- All repair work must be carried out by skilled personnel, when in doubt, always return the
tool to the distributor.
TOOL CAPACITY
Blind rivets 3.0/3.2mm ~ 4.0mm ~ 4.8/5.0mm standard – 2.4mm optional.
TOOL SPECIFICATIONS
Air supply pressure:
Output traction power:
Stroke:
Net weight:
IMPORTANT to follow the safety instructions for adequate protection
0.5Mpa ~ 0.7Mpa
8,400N ~ 11,760 N
16mm
1.30kgs
