- Page 1 USER MANUAL Intelligent Toilet Primus 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 1 2018-05-11 11:05:03...
- Page 2 Thank you for placing your confidence in us. Thank you for buying AXENT products. You can learn from this manual about the use of products and other important issues before initial start-up. Please follow the instructions in this manual carefully.
-
Page 3: Table Of Contents
CONTENT Application What can “AXENT Remote Control” do? 19 About “AXENT Remote Control” 19 Safety 20 Introduction Overview 23 Main 23 Remote Control 24 Operation Flush 25 25 Rear Wash Front Wash... -
Page 4: What Can "Axent Remote Control" Do
APPLICATION WHAT CAN “AXENT REMOTE CONTROL” 9:41 AM 100% Installing “AXENT Remote Control” makes phone can be used like the remote control. According to your request, Rear wash Lady wash Stop you can set the Volume, Position, Temperature and the running order of wash. -
Page 5: Safety
SAFETY CAREFULLY READ AND OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS BEFORE USING! AXENT WILL NOT BEAR ANY RESPONSIBILITY FOR DAMAGE OR LOSS RESULTING FROM FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS. ■ ■ This device is an electric appliance of class I and must be connected to a grounding system. - Page 6 SAFETY Danger! To reduce the risk of electrocution The socket circuit connected to the product must have residual current protective device with a ■ ■ rated residual operating current not exceeding 30mA. ■ ■ Please install the ground wire correctly in accordance with the relevant regulations of the state. Ensure that sockets and plugs are located at least 600 mm horizontally from the shower room or ■...
- Page 7 SAFETY ■ ■ Do not allow to hit against the ceramics. ■ ■ Do not allow to place the product upside down. ■ ■ Do not use radio equipment near the product. Do not allow to plunge into the news paper, paper diaper, sanitary napkins, etc., which are easy to ■...
-
Page 8: Overview
INTRODUCTION OVERVIEW [E330-01] MAIN Rear cover Manual Flush Button Nozzle Seat 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 7 2018-05-11 11:05:06... -
Page 9: Remote Control
INTRODUCTION REMOTE CONTROL INTERFACE When receiving remote control command, the main unit makes the following sound: One short «beep» effective command Two short «beep» ineffective command One long «beep» exceed the range of remote control Low power will reduce the effect of remote control, please replace the battery in time. PAIRING TO REMOTE CONTROL It is necessary only after you replaced your remote control. -
Page 10: Flush
If not stopped manually the Front Wash will stop automatically after 3 minutes. Stop AUTO MASSAGE Factory setting: Oscillating Set by “AXENT Remote Control”. When the Auto massage is on, massage started automatically During Rear or Front wash. 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 9 2018-05-11 11:05:08... -
Page 11: Water Volume
OPERATION WATER VOLUME During Rear or Front wash, ■ - Press « Reduce » to reduce the water volume. Reduce ■ - Press « Increase » to increase the water volume. Increase SPRAY ARM POSITION During Rear or Front wash, ■... -
Page 12: Eco Setting
OPERATION ECO SETTING Factory setting: Press « Fn » at the same time « Front Wash » to turn the function on or off. ■ - Short «beep». Front Wash ■ - Long «beep». When the ECO is on, the seat will be intelligently heated according to the user’ s usage habits. NIGHT LIGHT SETTING Factory setting: AUTO... -
Page 13: Spray Arm Cleaning
MAINTENANCE SPRAY ARM CLEANING Press « Fn » at the same time « Rear Wash » to extend the spray arm for cleaning. Rear Wash Clean the spray arm with a fabric or a soft bristle brush. Press « Stop » to retract the spray arm. Stop If no other functions are used, the spray arm will automatically retract after 3 minutes. -
Page 14: During Vacation
MAINTENANCE DURING VACATION If this product will not be in use for an extended period of time, please perform the following in this order. ■ - Disconnect the electrical power. ■ - Shut off the angle valve. WINTERIZATION Please ensure water temperatures will not drop below 4 °C (39 °F). Frost or frozen water will damage the system and may lead to leakage. -
Page 15: Replacing Batteries
MAINTENANCE REPLACING BATTERIES REMOVE BATTERIES Push cap and turn counter clockwise. And remove cap and batteries. INSTALL BATTERIES Make sure the batteries are oriented properly and install batteries and cap. Push cap and turn clockwise. 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 14 2018-05-11 11:05:12... -
Page 16: Troubleshooting
Rear or Front washing Instable water tem- Water pressure overload Turn angle-valve clockwise to reduce water pressure. perature MASSAGE Does not work Auto massage is OFF Turn on Auto massage by “AXENT Remote Control” app. 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 15 2018-05-11 11:05:13... - Page 17 TROUBLESHOOTING MALFUNCTION CAUSE REMEDY SEAT HEATER Low seat tempera- Seat temperature set too Increase seat temperature. ture Low seat temper- ature when initially Eco mode is on Please turn off ECO. seated Seat temperature Seat Low TEM Protection It is normal. Please adjust Seat temperature or reseated to reduce automati- will be activated automati- disable Seat Low TEM Protection.
-
Page 18: Dimension
DIMENSION [E330-01] ≥10 Unit: mm 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 17 2018-05-11 11:05:13... -
Page 19: Technical Data
TECHNICAL DATA ITEM DESCRIPTION Nominal Voltage 220 - 240 V~, 50 Hz 1050 W Power Consumption (Under the condition of cold water temperature 15 ± 2 °C and flow rate 550 mL/min) Max Power Consumption 1650 W Cable Length 1.5 m Hydrostatic Pressure Range 0. -
Page 20: Guarantee
GUARANTEE Dear Guest: Thank you for buying AXENT products. In case of minor malfunctions, please refer to troubleshooting of this manual. If the solutions of the troubleshooting do not resolve the issue, please contact customer support for further examination and repair. - Page 21 AXENT(Shanghai) Corporation Ltd. Add: A, C, D Rooms, 10F, No. 9 Zhenning Road, Changning District, Shanghai, China Tel: +86 21 5238 7080 E-mail: service@axentbath.com www.axentbath.com 224000015700 普莱智能 泰国款 操作说明书 (1.00-RC2).indd 22 2018-05-11 11:05:13...
