Summary of Contents for thomann swissonic Professional Router 2
- Page 1 Professional Router 2 router user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 07.09.2018, ID: 422678...
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 7 Safety instructions............................. 9 Features............................... 14 Installation and starting up........................ 15 Connections and controls........................19 Cleaning............................... 24 Troubleshooting............................25 Technical specifications........................ -
Page 4: General Information
General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual. -
Page 5: Further Information
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly. -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’... -
Page 7: Symbols And Signal Words
General information Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 8 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided.
-
Page 9: Safety Instructions
Safety instructions Safety instructions Intended use This device is used to wirelessly connect Wi-Fi-enabled devices to each other to form a wireless local area network or to connect to the Internet. Use the device only as described in this user manual. - Page 10 Safety instructions DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
- Page 11 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
- Page 12 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
- Page 13 Safety instructions NOTICE! Radio interference This device emits electromagnetic signals. This can cause interference due to overlapping radio waves. Do not use the device in locations where the use of wireless devices is prohibited. NOTICE! Locations subject to explosion hazards This device emits electromagnetic signals.
-
Page 14: Features
Features Features Wireless Dual Band Router (2.4 and 5 GHz) 4 operation modes: Router, Repeater (Extender), Access Point, wireless ISP 1 WAN port 4 LAN ports Diversity Detachable antennas Lockable Neutrik RJ-45 plugs on the front panel Built-in power supply 19"... -
Page 15: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 16 Installation and starting up Setting up Wi-Fi on the com‐ puter (Windows 10 operating system) Start the computer. Click the Windows Start icon and select ‘All apps’ . Click ‘Windows System è Control Panel è Network and Internet è Network and Sharing Center’ and select ‘Change adapter settings’ . Right-click on the displayed Internet connection and select ‘Properties’...
- Page 17 Installation and starting up Setting up Wi-Fi on the router Start the web browser of your PC. Enter http://192.168.1.1 in the address bar of the web browser. Confirm with [ENTER]. Enter user name and password and click ‘Login’ . The default user name and password are ‘admin’...
- Page 18 Installation and starting up To save the settings, click ‘Apply Changes’ . To discard the changes and return to the defaults, click ‘Reset’ . Setting up Wi-Fi connection Click the Networks icon in the taskbar. ð The available networks are displayed. Select the network you want to connect to.
-
Page 19: Connections And Controls
Connections and controls Connections and controls Front panel Professional Router 2... - Page 20 Connections and controls 1 Main switch. Turns the device on and off. 2 [WPS] Press [WPS] to add a new device to the wireless local area network. 3 [RST] Press [RST] for more than 5 seconds to reset the device to factory settings. 4 LED indicator lights illuminates as soon as the router is connected to the mains and ready for use.
- Page 21 Connections and controls 6 Detachable 2.4 GHz omnidirectional antenna 7 [LAN 1], [LAN 2] lockable Neutrik RJ-45 connectors for connection to local network devices Professional Router 2...
- Page 22 Connections and controls Rear panel router...
- Page 23 Connections and controls 8 [WAN] WAN port for connecting to the internet 9 [LAN 3], [LAN 4] LAN port for connection to local network devices 10 Connection socket for the power cable. Professional Router 2...
-
Page 24: Cleaning
Cleaning Cleaning Clean the unit with a dry, soft, lint-free cloth. Stubborn dirt can be removed with a slightly dampened cloth. Never use cleaners containing alcohol or thinner. router... -
Page 25: Troubleshooting
Press and hold [RST] for at least 10 seconds. The reset was successful when all LEDs are flashing. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Professional Router 2... -
Page 26: Technical Specifications
Technical specifications Technical specifications Operating supply voltage 100 – 240 V 50 / 60 Hz Dimensions (W × H × D) 438 mm × 44 mm × 180 mm Weight 2.1 kg Standard IP address 192.168.1.1 Standard user name admin Standard password admin router... -
Page 27: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 28 Notes router...
- Page 29 Notes Professional Router 2...
- Page 30 Notes router...
- Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
