- Page 1 Operating instructions Gas presence detector, model GPD-1000 Gas presence detector, model GPD-1000...
- Page 2 Operating instructions model GPD-1000 Page 4 - 7 © 12/2018 WIKA Alexander Wiegand SE & Co. KG All rights reserved. WIKA® is a registered trademark in various countries. Prior to starting any work, read the operating instructions! Keep for later use!
-
Page 3: Table Of Contents
Contents Contents 1. General information 2. Technical data 3. Instructions 4. Features 5. Battery installation and replacement 6. Sensor 7. Sensor replacement 8. Maintenance Declarations of conformity can be found online at www.wika.com. WIKA operating instructions model GPD-1000... -
Page 4: General Information
The general terms and conditions contained in the sales ■ documentation shall apply. Subject to technical modifications. ■ Gas presence detector model GPD-1000 should not be used on ■ systems that contain flammable refrigerants such as Propane, Isobutane, etc. Factory calibrations/DKD/DAkkS calibrations are carried out in ■... -
Page 5: Technical Data
< 3 g/year (0.1 oz/year) Sensor lifetime 30 hours Operating temperature 0 ... 50 °C Warm up time < 2 seconds Response time Instantaneous Reset time Instantaneous Probe length 300 mm Replacement sensor Part-No. 14291469 WIKA operating instructions model GPD-1000... -
Page 6: Instructions
7. If a leak exists, the sound will increase in rate and pitch and the LED will start flashing rapidly. 8. To turn the GPD-1000 off, press and hold the button for 3 seconds. 4. Features If the sensor is damaged, a sweeping alarm and a red-green flash will indicate the problem. -
Page 7: Battery Installation And Replacement
4. Slide battery cover back into place. 6. Sensor A GPD-1000 sensor will last between 25 and 30 hours of continuous use. A failed or failing sensor will be indicated in one of the following ways: 1. Unstable or erratic operation of the unit and many false alarms, even in pure air. - Page 8 WIKA subsidiaries worldwide can be found online at www.wika.com. WIKA Alexander Wiegand SE & Co. KG Alexander-Wiegand-Strasse 30 63911 Klingenberg • Germany Tel. +49 9372 132-0 +49 9372 132-406 info@wika.de www.wika.de WIKA operating instructions model GPD-1000...
