- Page 1 PROGRAMMING MANUAL Digital electronic key module Art. 3348B / 3348BM Passion.Technology. Design.
-
Page 2: Table Of Contents
Table of contents Warning Description ..................3 Programming and operation ............3 Entering the supercode ................3 Relay codes: first programming .............4 Using relay codes ..................4 Cancelling relay codes ................4 Bistable/Monostable operation ..............5 Anti-coercion function ................5 Programming the allowed errors number ..........6 Programming the relay 1 activation delay for a remote key input ..6 Actuator function ..................6 Technical specifications .............. -
Page 3: Description
Description Art. 3348B / 3348BM for mounting in iKall modular keypads for mixed access control - entry panel - video entry panel installations or stand-alone applications. OFF ON 1. Jumper for entering supercode 2. Connector to be used for connection to Simplebus system. -
Page 4: Relay Codes: First Programming
• If you make an error in entering the code, press the “key” button several times to cancel the operation. • You must always enter “E” at the end of the operation, whether during programming or normal use. • Modifying or changing the supercode resets all other programmed settings (including relay codes). •... -
Page 5: Bistable/Monostable Operation
Bistable/Monostable operation The relays can be programmed to operate in bistable (on/off) or monostable (timed) modes (the period of activation can also be set in the latter case). Bistable mode entering the value “0” sets the relay to activate when the code is first entered, then de-activate when it is next entered. Monostable mode entering a value in the range 1 to 99 sets the relay to activate when the code is entered and de-activate automatically once the specified period of time (1 to 99 seconds) has expired. -
Page 6: Programming The Allowed Errors Number
Actuator function One of the relays of 3348B can be used on the generic actuator command originating from the Simplebus Bus. Special programming is required on the external unit as described in the TMs for Art. 4680, 4680C, 4681 and for 1621, 1622. - Page 7 Cancelling the actuator function: 1. Enter “0” and “E” (start programming procedure code). 2. Check that the LED has lit up. 3. Enter the supercode (see "Entering the supercode"), then da “E”. 4. Enter the number “7” ("actuator" function) followed by “E”. 5.
-
Page 8: Technical Specifications
Technical specifications GENERAL INFO Available codes 402 total available codes: - one supercode; - 400 relay codes. The available codes can be distributed in any way between relay 1 and relay 2. Example: 245 different codes for relay 1, and 155 different codes for relay 2;... - Page 10 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
