Pump controller EC 531
27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
V-
DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8 AO1 AO2 V+
Digital outputs (V+)
out (4-20 mA) in
EC 531
AUTO
AUTO
0
0
1
2
o P
w
r e
D
g i
a t i
i l
p n
t u
( s
- 9
V+
V-
DI1 DI2 DI3 DI4 DI5 DI6 DI7 DI8 DI9 DI10 DI11 DI12 DI13 DI14 AI7 V-
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16 17 18 19 20
Installation guide
www.sulzer.com
47
AI1 AI2 AI3 AI4 V-
AI5 AI6
RJ45
Ethernet RS 485
Pt100/PTC
Esc.
4 3
V
D
) C
Pt100/Leak
AI8 V-
49 50 51 52
Bias +
+
-
Shld
Term.
Bias -
RS 232
USB
M
o
e d
m
-
S R
2
2 3
V-
RXD TXD RTS CTS
22 23 24 25 26
Advertisement
Table of Contents
Related Manuals for Sulzer EC 531
Summary of Contents for Sulzer EC 531
- Page 1 Pump controller EC 531 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 49 50 51 52 Bias + DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8 AO1 AO2 V+...
- Page 2 The content of this manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Sulzer. Sulzer assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
-
Page 3: Installation
INSTALLATION Mount the controller Mount the controller on a 35 mm DIN rail. The physical dimensions of the controller is: 86 x 160 x 60 mm (3.39 x 6.30 x 2.36 inch) (H x W x D). If it doesn’t easily snap onto the rail, you can pull the small tab at the bottom side of the unit, using a small screwdriver. -
Page 4: Factory Settings
Table 1: Terminals at the bottom side of the pump controller Factory settings Logic mode Name Term. (NO/NC) Voltage supply, 9–34 VDC Overflow level Digital in High level float Digital in Power fail Digital in Local mode Digital in Motor protector pump 1 Digital in Pump 1 set auto Digital in... - Page 5 Table 2: Terminals at the top side of the pump controller Term. Name Factory settings Logic mode (NO/NC) Digital out Alarm alert Digital out Pump ctrl pump 1 Digital out Pump ctrl pump 2 Digital out Digital out Digital out Personnel alarm Digital out Mixer ctrl...
- Page 6 4-20 mA Analog input connection. Recommended to use Analog Input 1 as Level sensor because highest resolution. Analog In 1-4 Analog input connection level sensor Figure 3 Analog input 5-8 for connection of Pt100 sensors (temperature sensor). Analog In 5-8 Figure 4 Connection of Pt100 use corresponding V- Use Analog In 5–6 for temperature sensor PTC and/or Bi-metallic switches.
- Page 7 Analog In 7–8 for leakage sensor. If several leakage sensors: connect the sensors in parallel. Analog In 7-8 Figure 6 Analog input connection leakage sensors Digital output connections. Recommendation is to use external relays together with a flyback diode to each relay according to figure.
- Page 8 CHECK YOUR INSTALLATION After the installation, there are possibilities to check the status of the digital and analog in- and outputs in the menus of EC 531. This could be used for validations of the installation and for fault tracking.
-
Page 9: Communication Ports
AquaProg. Select Modbus RTU or TCP and Modbus ID in settings. Cross reference table is available. First time a PC connects to EC 531, a wizard appears at the screen. Just follow the instructions on your PC. - Page 10 3.5.1 Communication parameters RS 485 The EC 531 can act as a slave or master in the RS 485 network. If EC 531 is set as master, all the surrounding units must be set as slaves. All the units in the RS 485 network must be using the same communication parameters; baud rate, parity and stop bits.
-
Page 11: Variable Speed Drive
50.15 FBA cw used P.02.36 EFB main cw 58.01 Protocol ena sel Modbus RTU 58.03 Node address Unique slave ID corresponding to EC 531 setting 58.04 Baud rate Same as EC 531 58.05 Parity Same as EC 531 58.06 Control profile ABB enhanced (default) 58.10 Refresh settings... - Page 12 1103 Ref1 select 8 = Comm 1604 Fault reset sel 8 = Comm If remote drive reset is enabled in EC 531 5302 EFB station ID (Node address) Unique slave ID corresponding to EC 531 setting 5303 EFB baud rate...
- Page 13 Select fieldbus CTRL for EC 531 operation P3.3.1.10 Fieldbus ref sel Select fieldbus for EC 531 speed control Note! Mark parity in EC 531 is the same as 2 stop bit. No parity in Vacon drive. Vacon 20 Variable speed drive P2.1 Remote control place selection...
- Page 14 Same parity as EC 531 Control • Auto Start OFF Note! Mark parity in EC 531 is the same as 2 stop bit. No parity in NFO drive. Enable “Run input” with a cable jumper between terminal 1 and 5 to allow Modbus control.
- Page 15 4.7 Schneider ATS 48 Soft starter COP menu: • Add Unique slave ID corresponding to EC 531 setting • tbr Same baud rate as EC 531 • FOr Same parity as EC 531 • tLP 1.8 if using default EC 531 setting •...
- Page 16 4.8 Supported function table Brand: Model: Type of unit: VFD / VSD Soft starter Energy meter Control: On / Off ctrl Reverse control Speed control Monitor: Fault Frequency Hz Speed RPM Torque % Torque Nm Motor voltage Motor current Motor power Power factor Input power L1 Volt...
- Page 17 TECHNICALDATAEC531 Electrical Installation category CAT II Power consumption < 5.0 W (without output load) Power supply 9–34 VDC SELV or Class 2 Environmental Ambient operation temperature -20 to +50 °C (-4 to +122 °F) Ambient storage temperature -30 to +80 °C (-22 to +176 °F) Humidity 0–95% RH non condensing Max altitude...
-
Page 18: How To Clean The Unit
Power off the unit. Only outside / front shall be cleaned by using a dry, soft cloth. A good choice would be the microfiber type of cloth. Gently wipe the EC 531 front in order not to scratch the overlay. If the dry cloth did not completely remove the dirt, do not press harder in an attempt to scrub it off. - Page 20 Sulzer Pump Solutions Ireland Ltd., Clonard Road, Wexford, Ireland Tel. +353 53 91 63 200, Fax +353 53 91 42 335, www.sulzer.com Copyright © Sulzer Ltd 2018...
