RAS-F(/F)
Technische Alternative RT GmbH
+ RCV-DL
A-3872 Amaliendorf, Langestr. 124
Vers. 2.0 EN
Tel +43 (0)2862 53635
mail@ta.co.at
Manual version 3
Wireless room sensor
and Receiver
RAS-F = Wireless room sensor
RAS-F/F = Wireless room
with temperature measurement
sensor with temperature
and humidity measurement
RCV-DL = Radio receiver
Wireless room sensors RAS-F starting with serial number 2286 and RAS-
F/F starting with serial number 1222 can only be used with radio receivers
RCV-DL starting with serial number 1867
Advertisement
Table of Contents
Related Manuals for Technische Alternative RAS-F
Summary of Contents for Technische Alternative RAS-F
- Page 1 RCV-DL = Radio receiver Wireless room sensors RAS-F starting with serial number 2286 and RAS- F/F starting with serial number 1222 can only be used with radio receivers RCV-DL starting with serial number 1867...
-
Page 3: Table Of Contents
Table of Contents Function description ......................... 4 Power supply ........................4 Setting up the RAS-F (/F) room sensor..................5 Coupling the receiver to the wireless sensor ............... 5 Coupling instructions ......................5 Deleting an allocation in the receiver ................... 7 Index specification ....................... -
Page 4: Function Description
Function description The wireless system always comprises a transmitter (= e.g. wireless room sensor) and a receiver. The receiver can receive the signals from up to 8 transmitters. The sensor sends the measurement values to the receiver every 10 minutes. If a manual change is made at the sensor (level adjustment +/-5 K, adjustment of the slider switch) or the measured values change (room temperature +/- 0.5K, room humidity +/- 1%) the values are transmitted immediately. -
Page 5: Setting Up The Ras-F (/F) Room Sensor
Setting up the RAS-F (/F) room sensor The battery supplied for the sensor must be inserted before commissioning. Coupling the receiver to the wireless sensor Push-buttons and 4 LEDs are used to couple the receiver to the particular wireless sensor. -
Page 6: Coupling Instructions
Coupling instructions Select a free address in the DL bus net Press the receiver button for at least 2 seconds Couple the transmitter with the receiver by pressing the button in the room sensor or inserting the battery. Supplementary explanations: A free address is selected by brief key presses at the receiver. -
Page 7: Deleting An Allocation In The Receiver
Measured room temperature (without offset values) (e.g. for UVR63) Room moisture (only type RAS-F/F, otherwise the fixed value 127% is output) Dew point temperature (only type RAS-F/F, otherwise the fixed value 0°C is out- put) Time in minutes since the last radio telegram (see instructions re index 5) Wireless receiver quality (only displayed with X2 controllers, UVR1611 and UVR63H from version 7.2) = Value between 0 and 1000, where 1000 represents... -
Page 8: Table Of Settings
ESR31, UVR61-3, UVR63 and UVR63H : Adjustment of the measurements takes place in the menu EXT DL (external sensors) Example: The external sensor 1 has address 1, the measured room tem- perature is imported without offset values (index 2). In the controllers ESR31, UVR61-3, UVR63 and UVR63H (version 5.0 up to 7.1) only the measured room temperature can be evaluated without offset values (index 2);... -
Page 9: Operation With X2 Controllers, Uvr1611 (From Version A3.00 And Serial Number 13286) And Uvr63H (From Version 7.2)
UVR63H (from version 7.2) The room sensor is used as a command and temperature measurement instrument for the Technische Alternative controllers. The reported signal corresponds to the room temperature changed using the rotary knob. The following signals are forwarded to the controller accord- ing to the switch setting: •... -
Page 10: Use As A Remote Control
Battery: Type CR2032, service life maximum 5 years When replacing the batteries, no new coupling process is necessary Accuracy rel. humidity: ± 3% RH from 20 to 80 % RH (RAS-F/F) Bus load of receiver: Radio frequency: 868.5 MHz Range in the open air: max. -
Page 11: Installation
Installation The sensor and the receiver must only be installed in dry rooms. The room sensor must be opened for mounting. A small screwdriver is used to press in the clamps beneath the temperature selection knob and sliding switch while simultaneously raising the cover. - Page 12 EU Declaration of conformity Document- Nr. / Date: TA17055 / 02/02/2017 Company / Manufacturer: Technische Alternative RT GmbH Address: A- 3872 Amaliendorf, Langestraße 124 This declaration of conformity is issued under the sole responsibility of the manufacturer. Product name: RAS-F, RAS-F/F...
- Page 13 EU Declaration of conformity Document- Nr. / Date: TA17057 / 02/02/2017 Company / Manufacturer: Technische Alternative RT GmbH Address: A- 3872 Amaliendorf, Langestraße 124 This declaration of conformity is issued under the sole responsibility of the manufacturer. Product name: RCV-DL...
- Page 16 Legal notice These assembly and operating instructions are protected by copyright. Use outside the copyright requires the consent of the company Technische Alternative RT GmbH. This applies in particular to reproductions, translations and electronic media. Technische Alternative RT GmbH A-3872 Amaliendorf Langestraße 124...
