It is the responsibility of the employer/issuer of this equipment to ensure that it is
used in a manner consistent with these instructions. Failure to do so could result in
series injury or death.
For further reading and additional information, see Section 10.4 for a listing of
relevant standards with which you should be familiar.

10.2: Performance Specifications

The EcoAnchor has been engineered to function as a counter-weight anchor for fall
arrest and travel restraint applications. The critical specifications of construction and
performance are shown below:
EcoAnchor Bladder:
Coefficient of Friction:
Surface loading (full):
Maximum allowable slope/grade:
Dimensions – full (SAE):
Dimensions – full (Metric):
Maximum User Capacity:

10.3: Labels and Markings

The label shown below must be present on the product and must be legible. If it is
not, remove the product from service.
Located on corner of bladder adjacent to vent valve
10-4: Standards and references
Below is a listing of standards that are applicable to the construction and use of this
product. FallTech strongly encourages that all employers acquire and utilize these
documents for the creation of your own fall protection policies and your individual fall
protection plans. Users of this product should also be familiar with this information as
well.
OSHA Standards bear the force of law on a federal level. Some states have their
own regulations which are locally enforced – check with your State Department of Labor
for specific requirements which may be enforced in your area. OSHA Standards can be
accessed for free at www.osha.gov.
Anchor Ring:
Empty Weight:
Full Weight:
Neoprene – FED STD 191 pt. 1520
Alloy Steel – 5,000 lb. min. strength
>.65
17 lbs.
947 lbs.
42 lbs./ft² or .29 psi
10°
57" x 57" x 8.75"
144.8 cm x 144.8 cm x 22.2 cm
310 lbs. per user
