Summary of Contents for Sentera Controls MTP-G010-AT
- Page 1 MTP-G010-AT ACTIVE POTENTIOMETER Mounting and operating instructions...
- Page 2 PRODUCT DESCRIPTION INTENDED AREA OF USE TECHNICAL DATA STANDARDS OPERATIONAL DIAGRAM WIRING AND CONNECTIONS MOUNTING INSTRUCTIONS IN STEPS VERIFICATION OF INSTALLATION INSTRUCTIONS TRANSPORT AND STORAGE WARRANTY AND RESTRICTIONS MAINTENANCE MIW-MTP-G010-AT-EN-000 - 29 / 08 / 2018 2 - 7 www.sentera.eu...
- Page 3 In case there are any questions that are not answered, please contact your technical support or consult a professional. MIW-MTP-G010-AT-EN-000 - 29 / 08 / 2018 3 - 7 www.sentera.eu...
- Page 4 POTENTIOMETER PRODUCT DESCRIPTION MTP-G010-AT potentiometer is intended for direct control of EC fans / motors and actuators. It requires a supply voltage of 24 VDC or 24 VAC and provides a stepless output signal that can be set by a rotary knob with off-position. The output range is adjustable via two internal trimmers between Vmin (0—7 VDC) and Vmax (3—10 VDC).
- Page 5 Do the wiring according to the wiring diagram (see Fig. 1 Wiring and connections). Fig. 1 Wiring and connections Vmin adjustment Vmax adjustment trimmer trimmer Supply voltage: 24 VAC or VDC Output voltage: 0, Vmin—Vmax MIW-MTP-G010-AT-EN-000 - 29 / 08 / 2018 5 - 7 www.sentera.eu back to the table of contents...
- Page 6 Mount back the cover and secure it with the nut. Put back the knob and turn it to off position. Turn on the power supply. MIW-MTP-G010-AT-EN-000 - 29 / 08 / 2018 6 - 7 www.sentera.eu back to the table of contents...
- Page 7 In case of heavy pollution, clean with a non-aggressive product. In these circumstances the unit should be disconnected from the supply. Pay attention that no fluids enter the unit. Only reconnect it to the supply when it is completely dry. MIW-MTP-G010-AT-EN-000 - 29 / 08 / 2018 7 - 7 www.sentera.eu...
