ENDA EDT1411P Manual

Please read this document carefully before using this product. The guarantee will be
invalidated if the device is damaged by not following instructions detailed in the
manual. The company shall not be responsible for any damage or losses however
caused, which may be experienced as a result of the installation or use of this product.
ENDA EDT1411P TEMPERATURE CONTROLLER
Thank you for choosing ENDA EDT1411 temperature controller.
* 35 x 77mm sized.
* On-Off control.
* Single contact output for cooling control.
* Single NTC probe input.
* Offset value can be entered for NTC probe.
* Compressor protection parameters can be entered.
* In the case of probe failure, output state can be
selected on, off or periodical running.
* Upper and lower limits of the setpoint can be adjusted.
* Defrosting duration and interval can be adjusted.
* Temperature unit can be selected °C or °F.
* Upper and lower limits of the alarm value can be adjusted depending on the setpoint value.
* CE marked according to European Norms.
Output Supply Voltage
230V AC +%10 -%20 EDT1411-NTC-230P
Röle -16A 24V AC %10 ± EDT1411-NTC-24P
9-24V AC/DC %10 ± EDT1411-NTC-12P
Connection Diagram
ENDA EDT1411 is intended for installation in control panels. Make sure that the device is used
only for intended purpose. The electrical connections must be carried out by a qualified staff
and must be according to the relevant locally applicable regulations. During an installation, all of the
cables that are connected to the device must be free of electrical power. The device must be
protected against inadmissible humidity, vibrations, severe soiling and make sure that the operation
temperature is not exceeded. The cables should not be close to the power cables or components.
ENDA
ENDA
INDUSTRIAL ELECTRONICS INDUSTRIAL ELECTRONICS
EDT1411-NTC-230VAC-P EDT1411-NTC-24VAC-P
DIGITAL DEFROST THERMOSTAT DIGITAL DEFROST THERMOSTAT
SN: XXXXXXXXX SN: XXXXXXXXX
NTC
SENSOR
1 2 3 4 5 6 7 8 9 10 11 12 1 2 3
Holding screw
0.4-0.5Nm.
NOTE:
Fuse
SUPPLY: F 100 mA
Switch
250V AC
4 Line
184-253V AC
50/60Hz 4VA
5
Neutral
Fuse should
Cable size: 1,5mm²
be connected
°F
ENDA
Order Code
ENDA
INDUSTRIAL ELECTRONICS
EDT1411-NTC-SM-P
DIGITAL DEFROST THERMOSTAT
SN: XXXXXXXXX
NTC
SENSOR
4 5 6 7 8 9 10 11 12 1 2 3 4 5 6
Equipment is protected throughout
by DOUBLE INSULATION
Note:
1) Mains supply cords shall meet the requirements of
IEC 60227 or IEC 60245.
230V AC
2) In accordance with the safety regulations, the power
Supply
supply switch shall bring the identification of the
relevant instrument and it should be easily
accessible by the operator.

Technical Specifications

ENVIRONMENTAL CONDITIONS
Ambient/storage temperature
Max. relative humidity
Rated pollution degree
Height
Do not use the device in locations subject to corrosive and flammable gasses.
ELECTRICAL CHARACTERISTICS
Supply voltage
Power consumption
Wiring
°C
Scale
SET Sensitivity /Accuracy
SET
Time Accuracy
Indicator
EDT1411
EMC
Safety requirements
OUTPUT
COMPRESSOR
Life expectancy for relay
CONTROL
Control type
Control algorithm
Hysteresis
HOUSING
Housing type
Dimensions
Weight
Enclosure material
While cleaning the device, solvents (thinner, benzine, acid etc.) or corrosive materials must not be used.
Dimensions
°F
ENDA
NTC
SENSOR
7 8 9 10 11 12
SÝSEL MÜHENDÝSLÝK ELEKTRONÝK SAN. VE TÝC. A.Þ.
Yukarý Dudullu Barbaros Cad. Kutup Sok. No:20 34775 - ÜMRANÝYE/ÝSTANBUL/TURKEY
Tel : +90 216 499 46 64 Pbx.
1/3
url : www.enda.com.tr
0 ... +50°C/-25 ... 70°C (with no icing)
80 , up to % 31°C decreasing linearly 50% at
According to EN 60529 Front panel : IP65
Rear panel : IP20
Max. 2000m
230V AC +10% -20% or 12/24V AC/DC ±10%, 50/60Hz or 9-30V DC / 7-24V AC ±10%.
Max. 4VA
2.5mm² screw-terminal connections.
-50.0 ... +110.0°C (-58.0 ... +230.0°F)
0.1°C / ±1 °C
(±1%-15sec) for hour unit, (±1%-1sec) for minute unit
4 digits, 12.5mm, 7 segment yellow LED
EN 61326-1: 1997, A1: 1998, A2: 2001 (Performance criterion B is satisfied for EMC tests.
The device is designed to operate in controlled electromagnetic environment)
EN 61010-1: 2001 (Pollution degree 2, overvoltage category II)
For EDT1411-NTC-XXP ; Relay: 240V AC, 8A (for resistive load), NO;
1 HP 230V AC Cos = 0.5 (for inductive load)
For EDT1411-NTC-XXP ; Mechanical 30.000.000 operation. (None load)
240V AC ,16A in the resistive load 30.000 operation.
Single-setpoint control
On-Off control
Adjustable between 0.1 ... 20.0°C.
Suitable for flush-panel mounting.
W77xH35xD71mm
Approx. 250g (Equipment and prob a fter packing
Self extinguishing plastics
77mm
For removing mounting clamps:
Push the flush-mounting
°C
clamp in direction 1 as shown
SET in the figure below. Then, pull
SET
out the clamp in direction 2.
EDT1411
Flush mounting
clamp
Panel cut-out
71mm
1
Fax : +90 216 365 74 01
40 °C
)
Depth
71mm 5mm
Flush mounting
Panel
Rubber
clamp
2
packing
Note : 1) Panel thickness
should be maximum
7 mm.
2) If there is no 60mm
free space at the back
side of the device, it
would be difficult to
remove it from the
Panel.
EDT1411P-E-01-R
