Manual
WARNING!
POTENTIAL SHOCK HAZARD
WARNING!
which could cause property damage, personal injury or death. Read and follow all warnings and
instructions in this manual prior to operating grill.
WARNING!
•
For Outdoor Use Only
•
When using powered appliances, basic safety precautions, including the following,
should always be followed to reduce the risk of fire, electric shock, personal injury and
material damage.
•
Retain this manual for future reference.
N415-0478CE AUG 07.17
Failure to follow the instructions in this manual could result in fire or burn hazard
Wolf Steel Europe BV
Poppenbouwing 29-31, 4191 NZ Geldermalsen,
CCI No. 51509970, NETHERLANDS
info@napoleonproducts.nl
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
DO NOT DISCARD
PRO285E
This appliance is rated for
220-240 V - 50/60 Hz
2200 W
www.napoleongrills.com
1
Advertisement
Table of Contents
Related Manuals for Napoleon PRO285E
Summary of Contents for Napoleon PRO285E
- Page 1 APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. DO NOT DISCARD PRO285E This appliance is rated for WARNING! 220-240 V - 50/60 Hz POTENTIAL SHOCK HAZARD 2200 W WARNING! Failure to follow the instructions in this manual could result in fire or burn hazard which could cause property damage, personal injury or death.
-
Page 2: Year Limited Warranty
NAPOLEON. NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and workmanship from the date of purchase, for the following period: Aluminum castings / stainless steel base ........... -
Page 3: Safe Operating Practices
• Do not operate the grill with a temperature controller that has a damaged cord or plug. If the supply cord is damaged, it must be replaced by a special assembly available from Napoleon or a Napoleon authorized dealer. •... - Page 4 DIMENSIONS PRO285E GRILL 37cm X 54cm (IRREGULAR) = 1840 cm2 (14 1/2” X 21 1/4” (IRREGULAR) = 285 in 74cm [29”] 47cm [18 1/2”] OVERALL HEIGHT 38cm [14 3/4”] (64cm [25 1/5”] 21cm [8 1/4”] (GRILL HEIGHT) 31cm [12 1/4”] 40cm [15 3/4”]...
-
Page 5: Cooking Instructions
Preheat on HIGH for 15-20 minutes with a closed lid, then set to desired temperature. This is a guideline for cooking in outdoor temperature of 22⁰C. To add a trademark taste to your cooking, try the Napoleon woodchip smoker as an optional accessory with mesquite- or hickory-flavoured woodchips. -
Page 6: Troubleshooting
Troubleshooting Problem Possible Causes Solution No heat Temperature probe turned off. Turn temperature probe to maximum setting. No power. Ensure temperature probe is fully seated in grill plate and properly plugged into outlet. Try another outlet. Check for tripped circuit breaker. Reset. Turn temperature probe to maximum setting. -
Page 7: Optional Stand
OPTIONAL SHELF OPTIONAL STAND N415-0478CE AUG 07.17 www.napoleongrills.com... -
Page 8: Cleaning Instructions
Cleaning Instructions WARNING! Always wear protective gloves and safety glasses when servicing your grill. WARNING! To avoid the possibility of burns, maintenance should be done only when the grill is cool. Avoid unprotected contact with hot surfaces. Ensure grill is turned off. Clean grill in an area where cleaning solutions will not harm decks, lawns, or patios. - Page 9 Cleaning Steps Disassembly: 1. Unplug the cord from wall and remove the thermostat. 2. Remove cooking grids. 3. Depress spring clip and lift heating element out of grill. 4. Remove the base liner. N415-0478CE AUG 07.17 www.napoleongrills.com...
- Page 10 Reassembly: 1. Reinsert the base liner. 2. Place the curved ends of the heating element back into its support clips. Clip the heating element into place. 3. Reinsert the thermostat and cooking grids. www.napoleongrills.com N415-0478CE AUG 07.17...
-
Page 11: Ordering Replacement Parts
SERIAL NUMBER: (Record information here for easy reference) Before contacting the Customer Solutions Department, check the Napoleon Grills Website for more extensive cleaning, maintenance, troubleshooting and parts replacement instructions at www.napoleongrills.com. Contact your local distributor directly (refer to the distributor contact list provided with your grill) for replacement parts and warranty claims. -
Page 12: Parts List
Z305-0013 NGZ GRID, COOKING CAST RIGHT (285) N325-0083 NGZ, HANDLE LID (PRO285) N370-0861-SER KIT, BRACKET FRONT/REAR ELEMENT Z585-0015 NGZ, BASE LINER, PORCELAIN COATING (PRO285E) Z010-0048 NGZ, ELEMENT (PRO285E) Z135-0003 NGZ, CASTING BASE BLACK (PRO285E) Z690-0001 NGZ, THERMOSTAT ASSY (PRO285E) N010-1009-SER... -
Page 13: Parts Diagram
Parts Diagram N415-0478CE AUG 07.17 www.napoleongrills.com... -
Page 14: Correct Disposal Of This Product
Correct Disposal Of This Product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. - Page 15 Notes N415-0478CE AUG 07.17 www.napoleongrills.com...
- Page 16 Napoleon products are protected by one or more U.S. and Canadian and/or foreign patents or patents pending. N415-0478CE www.napoleongrills.com N415-0478CE AUG 07.17...
