Summary of Contents for LVI MagniLink Voice 2
- Page 1 User Manual MagniLink Voice 2 LVI Low Vision International Verkstadsgatan 5 Tel: +46 470-727700 info@lvi.se SE-352 46 Växjö Faks: +46 470-727725 www.lvi.se...
-
Page 3: Table Of Contents
6.8 Extra voices on a USB stick ............30 6.9 Quality of OCR conversion ............31 6.10 Maintenance charging .............. 31 Ergonomics ................... 32 Troubleshooting ................33 Technical information ..............34 10 Declaration of Conformity ............37 User Manual 7943064e | MagniLink Voice 2... - Page 4 MagniLink Voice 2 User Manual 7943064e | MagniLink Voice 2...
-
Page 5: About Lvi
MagniLink Voice 2 1 About LVI LVI Low Vision International AB was founded in 1978 and is one of the world's leading manufacturers of equipment for persons with visual impairments. Development of new products takes place in close cooperation with users and professional staff within the low vision rehabilitation industry. -
Page 6: Introduction To The Magnilink Voice
MagniLink Voice meets all the requirements for CE marking of medical devices in accordance with Directive 93/94/EEG. Our products comply with MDD 93/94/EEC with additions from Directive 2007/47/EC User Manual 7943064e | MagniLink Voice 2... -
Page 7: Safety Information
If in doubt, contact your supplier. Warning The product is supplied packed in a plastic bag. To avoid risk of suffocation, keep the bag out of the reach of children and infants. User Manual 7943064e | MagniLink Voice 2... -
Page 8: Unpacking
Open the box and take out the MagniLink Voice; remove the packaging. 4.1 Packaging The packaging consists of the following packaging material (LVI recommends that the packaging be kept in case you have to return the system or you need to move it): ... -
Page 9: Installation
3. HDMI in Here you can plug in an external image source. It is then possible to switch the image source using the hand control. 4. Power supply The power adaptor is plugged in here. User Manual 7943064e | MagniLink Voice 2... - Page 10 The unit has three USB ports. The hand control must be connected to one of these ports. If you wish to save or open a document, you can connect a USB memory stick. User Manual 7943064e | MagniLink Voice 2...
-
Page 11: Use
MagniLink Voice 2 6 Use 6.1 Placing paper The unit is able to OCR-process an A4 sheet of paper. Position the short side of the paper between the guides on the unit’s foot. User Manual 7943064e | MagniLink Voice 2... -
Page 12: Profiles And Settings
To switch between simple and advanced profile, hold the control (E) pressed for five seconds. To go into settings, hold the controls (E) and (F) pressed for three seconds. User Manual 7943064e | MagniLink Voice 2... -
Page 13: Simple Profile
MagniLink Voice 2 6.3 Simple profile 6.3.1 Quick guide simple profile without monitor User Manual 7943064e | MagniLink Voice 2... - Page 14 MagniLink Voice 2 6.3.2 Quick guide simple profile with monitor User Manual 7943064e | MagniLink Voice 2...
- Page 15 This button is used to take a picture, OCR process the text and read aloud the result. If you hold the button in for more than two seconds the text is added to a new page. User Manual 7943064e | MagniLink Voice 2...
-
Page 16: Advanced Profile
MagniLink Voice 2 6.4 Advanced profile 6.4.1 Quick guide advanced profile without monitor User Manual 7943064e | MagniLink Voice 2... - Page 17 MagniLink Voice 2 6.4.2 Quick guide advanced profile with monitor User Manual 7943064e | MagniLink Voice 2...
- Page 18 This button is used to take a picture, OCR process the text and read aloud the result. If you hold the button in for more than two seconds the text is added to a new page. User Manual 7943064e | MagniLink Voice 2...
- Page 19 "handle document" and then press the control. Rotate the function control (E) again until the unit says “file format” and press the control. Rotate the control until the desired format is spoken and press the control to select it. User Manual 7943064e | MagniLink Voice 2...
- Page 20 "column mode" and then press the control. Normally the column mode in on, but it is necessary to turn it off when you are processing text that you do not want to have read aloud in column form. User Manual 7943064e | MagniLink Voice 2...
- Page 21 Rotate the function control (E) again until the unit says “contrast level”. It is now possible to change the contrast level by rotating the level control (F). This setting only has an effect if any artificial colours are selected. User Manual 7943064e | MagniLink Voice 2...
-
Page 22: Settings
MagniLink Voice 2 6.5 Settings 6.5.1 Quick guide settings without monitor User Manual 7943064e | MagniLink Voice 2... - Page 23 MagniLink Voice 2 6.5.2 Quick guide settings with monitor User Manual 7943064e | MagniLink Voice 2...
- Page 24 Other settings have a setting that you can switch on or off by pressing the control. F. Level control Used to set font size and lighting. G. Button This button is used to exit the settings menu. User Manual 7943064e | MagniLink Voice 2...
- Page 25 (E) again until the unit says “standby mode” and press the control. Rotate the function control again (E) until the desired time is read aloud and then press the control to select it. User Manual 7943064e | MagniLink Voice 2...
- Page 26 Then rotate the function control (E) until the unit says "lighting". It is now possible to turn the lighting on and off by pressing the function control (E) and adjust the lighting by rotating the level control (F). User Manual 7943064e | MagniLink Voice 2...
- Page 27 USB memory stick in order for the unit to find them. Factory profile Rotate the function control (E) until the unit says "factory profile" and then press the control. User Manual 7943064e | MagniLink Voice 2...
- Page 28 Rotate the function control again(E) until the desired option is read aloud and then press the control. It is possible to select between display mode, column selector, column mode, navigation, automatic language identification and speaking voice and no function. User Manual 7943064e | MagniLink Voice 2...
-
Page 29: Quick Guide Computer Mouse
MagniLink Voice 2 6.6 Quick guide computer mouse User Manual 7943064e | MagniLink Voice 2... -
Page 30: Computer Mouse
“voices are ready to be used”. It is then possible to go into the menu and change voices and language settings to one of the new voices. User Manual 7943064e | MagniLink Voice 2... -
Page 31: Quality Of Ocr Conversion
To further extend battery life, we recommend that you use your MagniLink Voice once a month with just the battery (disconnect the mains adapter) until the battery is completely discharged. User Manual 7943064e | MagniLink Voice 2... -
Page 32: Ergonomics
If you use the device for long periods of time, there is a risk of repeated movements causing you pain in your neck, shoulders and back. Your eyes can also get tired from looking at a screen for too long. User Manual 7943064e | MagniLink Voice 2... -
Page 33: Troubleshooting
Check that the document is not rotated through more than 15 degrees. If the above has been checked and it is still not possible to make the unit function normally. Contact a competent service engineer or LVI. User Manual 7943064e | MagniLink Voice 2... -
Page 34: Technical Information
Transport and storage -20°C – +60°C Operation: +5°C – +25°C Relative humidity <80% Document size Light File format TXT, RTF, PDF Language options BE, DE, DA, NL, UK, US, FI, FR, IT, NO, ES, SE User Manual 7943064e | MagniLink Voice 2... - Page 35 Recycling helps in the management of our natural resources. For more detailed information regarding the recycling of this product, you can contact your municipality, your waste management company or the store where you purchased the product. User Manual 7943064e | MagniLink Voice 2...
- Page 36 MagniLink Voice 2 User Manual 7943064e | MagniLink Voice 2...
-
Page 37: Declaration Of Conformity
MagniLink Voice 2 10 Declaration of Conformity User Manual 7943064e | MagniLink Voice 2... - Page 38 Quick guide simple profile with monitor ..........14 Quick guide simple profile without monitor ........13 Safety information .................. 7 Settings ....................22 Simple profile ..................13 Technical information ................34 Troubleshooting ................... 33 Unpacking ....................8 Use ......................11 User Manual 7943064e | MagniLink Voice 2...
