Summary of Contents for LVI Magnilink visus
- Page 1 User Manual...
- Page 2 LVI Low Vision International Tel: +46 470 – 727700 Verkstadsgatan 5 E-mail: info@lvi.se Fax: +46 470 – 727725 352 46 Växjö Internet: www.lvi.se MagniLink Visus user manual 7942138a...
-
Page 3: Initial Operation
Fit the cable to the charger and plug it into the end of the handle on the MagniLink Visus (A). The charging indicator around the power connector will illuminate in red as the MagniLink Visus is charging and will extinguish when charging is complete. A full charge takes about 3 hours. - Page 4 Short press Press for 3-seconds Image freeze Display brightness Focus near/far Battery level Change artificial- Image mode colour Magnification level Illumination on/off...
- Page 5 (E) will cycle between the various image modes: full-colour, white-on- black and black-on-white and artificial-colour. You should choose the mode that gives you the best image for what you are viewing. The MagniLink Visus will re-use your last magnification, image mode and focus settings when next powered on.
- Page 6 Pressing the button again will return to the close focus setting. Stability Leg The MagniLink Visus is provided with a flip out leg, located around the lens on the underside. Simply flip it out fully to help maintain the ideal distance from the item you are reading.
- Page 7 number to the phone. Press the button (G) and the image will freeze; press again to return to the live image. The frozen image is not stored and cannot be read out of the unit. Illumination To facilitate reading backlit objects such as mobile phones or a computer screen, the lighting can be turned off.
- Page 8 If no movement is detected for 8 minutes the unit will power off completely and require you to press a button to wake it. If the battery is depleted, the MagniLink Visus will power-off and will not power on again until it is charged.
- Page 9 Alternative charging The MagniLink Visus can be charged from the USB port of a computer or by many standard chargers for portable consumer devices. The connector used is an industry standard and all such chargers should be compatible though charging times will vary.
- Page 10 Technical Data MagniLink Visus 3.4 (MLVISUS3,4) 100V – 240Vac 50/60Hz with supplied adaptor Charger Supply 5V dc, micro-USB connector Unit supply voltage 3.4”-diagonal AMOLED 16:9 Display Operating temperature 0°C to 45°C Recharging time 3 hours with supplied charger Run time From 2 hours in positive mode up to over 4 hours in negative.
- Page 11 Declaration of Conformity We, Ash Technologies Ltd., declare under our sole responsibility that the products MagniLink Visus 3.4 and MagniLink Visus 4.3 of the brand LVI (Low Vision International), to which this declaration relates, are in conformity with the following standards or other normative documents:...
