EVO Manufacturing EVO-1121B 2007+ Jeep JK Evap Skid Installation Instructions

Part#

EVO-12057B

EVO-12058B

EVO-770048

Installation photos shown are on a 2012 + Jeep Wrangler JK, for those installing

the EVO Evap Skid on a 07-11 Jeep JK follow the same install procedures.

Keep All Mounting Bolts loose until all bolts are installed into place. Then tighten all bolts.

Throughout the install there is no need to remove any of the factory hoses or factory evap

mounting bracket. You will only be required to remove the factory bracket from the

EVO-1121B 2007+ Jeep JK Evap Skid

NOTES PLEASE READ BEFORE INSTALL

crossmembers.

Description

Evap Main Skid

Evap Skid Rear Mount

EVO Evap Hardware Pack

Qty

Table of Contents

Need help?

Do you have a question about the EVO-1121B 2007+ Jeep JK Evap Skid and is the answer not in the manual?

Page 1 EVO-1121B 2007+ Jeep JK Evap Skid Part# Description EVO-12057B Evap Main Skid EVO-12058B Evap Skid Rear Mount EVO-770048 EVO Evap Hardware Pack Installation photos shown are on a 2012 + Jeep Wrangler JK, for those installing the EVO Evap Skid on a 07-11 Jeep JK follow the same install procedures.
Page 2 1. Loosen the two factory front evap skid bolts so that about ¼” thread are showing. 2. Loosen and remove the rear factory evap skid bolt completely. 3. Loosely install the EVO-12058B Evap Skid Rear Mount Plate using the rear factory evap skid bolt , the rear mount plate should be installed so that the plate is sandwiched between the crossmember and factory evap bracket,...
Page 3 5. Loosely secure the front of the EVO Evap Main Skid with the two factory front evap bolts, leaving a few threads showing. 6. Install the supplied hardware tightly securing the EVO evap main skid to the EVO evap rear mount plate.
