Summary of Contents for dji Osmo Pocket

  • Page 1 OSMO POCKET User Manual v1.0 2018.12...
  • Page 2: Using This Manual

    Scan the QR code to the right or search for "DJI Mimo" on the App Store or Google Play. The Android version of DJI Mimo is compatible with Android v5.0 and later. The iOS version of DJI Mimo is compatible with iOS v10.0 and later.
  • Page 3: Table Of Contents

    Contents Using this Manual Legend Read Before First Use Downloading the DJI Mimo App Introduction Overview Activating Osmo Pocket Charging Osmo Pocket Operation Button Feature Adjusting the Gimbal Manually Operating the Touch Screen Storing Photos and Videos Status LED Descriptions...
  • Page 4: Introduction

    OSMO POCKET User Manual Introduction Osmo Pocket is a handheld gimbal camera that combines mobility and stability in one device. It shoots sharp 12 MP photos and stable video at up to 4K 60fps. The onboard touch screen displays a live view from the camera and can control camera and gimbal movements. Connect a mobile device to the DJI Mimo app where professional-quality videos can be created and shared to social media instantly in Story mode.
  • Page 5: Activating Osmo Pocket

    OSMO POCKET User Manual Activating Osmo Pocket When using Osmo Pocket for the first time, activation is required through DJI Mimo. Follow the steps below to activate. 1. Remove the cover on the universal port and choose a lightning or USB-C smartphone adapter to connect to Osmo Pocket.
  • Page 6: Operation

    In the touch screen settings page, press once to go back to camera view. Adjusting the Gimbal Manually The tilt angle of Osmo Pocket can be adjusted manually. In Motionlapse, the pan angle can also be adjusted manually.
  • Page 7: Operating The Touch Screen

    OSMO POCKET User Manual Operating the Touch Screen The touch screen displays the camera view after Osmo Pocket is powered on, as well as the shooting mode, battery level, and microSD card information. Swipe Down Swipe down on the touch screen to enter the settings page. Swipe left or right to select between Glamour Effects, Superfine, and Save Settings (according to the shooting mode), System Settings, Screen Settings, and Brightness.
  • Page 8 OSMO POCKET User Manual Swipe Up Swipe up on the touch screen to enter the gimbal settings page. Re-center Tap to re-center the gimbal. Flip Tap to switch the camera between facing forward and backward. Follow Tap to switch between Slow Follow and Fast Follow. In Slow Follow, the gimbal responds slower, but the movement is smoother.
  • Page 9: Storing Photos And Videos

    Storing Photos and Videos The footage shot on Osmo Pocket can be stored on a mobile device and a microSD card (not provided). If there is no microSD card inserted, only low bitrate video can be stored on a mobile device.
  • Page 10: Dji Mimo App

    Home: tap to return to Home. Edit: tap to edit footage from Osmo Pocket or import and edit footage from a mobile device. Profile: register or log in to a DJI account. View works and settings, check likes and followers, send messages to other users, and connect with the DJI Store and Academy.
  • Page 11 OSMO POCKET User Manual 4. microSD Card Information : displays either the remaining number of photos that can be taken or the duration of 25:56 video that can be recorded according to the current shooting mode. 5. Flip : tap to switch the gimbal facing forward or backward.
  • Page 12: Updating Firmware

    Make sure there is nothing obstructing the gimbal when Osmo Pocket is powered on. Osmo Pocket is not water resistant. DO NOT use any liquid cleansers. Only use a soft dry cloth to clean Osmo Pocket.
  • Page 13: Specifications

    OSMO POCKET User Manual Specifications General Name Osmo Pocket Model OT110 Dimensions 121.9×36.9×28.6 mm Weight 116 g Input 5 V/2 A or 5 V/1 A Output 5 V/500 mA Gimbal Angle Vibration Range ±0.005° Controllable Range Pan: -230° to +50°, Roll: ±45°, Tilt: -95° to +50°...
  • Page 14: After-Sales Information

    1080 30fps video and should only be used for reference.) Charging Time 73 mins (when using a USB adapter of 5 V/2 A) After-Sales Information Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and support. © 2018 DJI All Rights Reserved.
  • Page 15 DJI Support http://www.dji.com/support This content is subject to change. Download the latest version from www.dji.com/osmo-pocket OSMO is a trademark of DJI. Copyright © 2018 DJI OSMO All Rights Reserved.
