This Quick Reference Guide is intended to supplement the Instruction Booklet.
In order to ensure safe operation and optimum performance,
TROUBLESHOOTING CHART
Question
Why won't my unit turn on?
Why is my unit turning
itself off?
Can I change my temperature or
plate selection when the unit is
already cooking?
Can I sear when I'm
already cooking?
Are the parts and accessories
dishwasher safe?
Food residue is sticking to the
plates. How do I clean them
without damaging them?
IMPORTANT!
Do not throw away. Keep for future reference.
please read the entire Instruction Booklet.
Answer/Solution
Check to make sure your unit is plugged into a
functional outlet.
Contact Customer Service at 1-800-726-0190.
It is possible the unit overheated. Wait for the unit to
cool down and try again. If it does not turn back on,
contact Customer Service at 1-800-726-0190.
If your Griddler
Deluxe is not turned off or if you do
®
not change any settings, it will shut off automatically
after 2 hours. This is a safety feature. To reactivate,
simply turn either knob.
Yes. To change temperature of your current plate
selection, simply turn the plate's temperature dial and
the unit will adjust automatically. To change your plate
selection, simply turn the temperature dial for your new
selection.
Yes. Simply press the SEAR button(s) and the plates will
preheat to sear temperature. We recommend you take
the food off during SEAR preheat. Once the SEAR cycle
is complete, the unit will revert back to previously
selected temperatures.
Yes, all removable parts are dishwasher safe. Do not
immerse or put the base of the unit in the dishwasher.
Clean it and the control panel with a damp cloth.
Use the scraper tool provided to scrape off any excess
food buildup. Do not use metal utensils to clean the
plates as they can damage the nonstick coating.
Advertisement
Table of Contents
Related Manuals for Cuisinart Griddler Deluxe
Summary of Contents for Cuisinart Griddler Deluxe
- Page 1 TROUBLESHOOTING CHART Subject Question Answer/Solution Check to make sure your unit is plugged into a functional outlet. Why won’t my unit turn on? Contact Customer Service at 1-800-726-0190. Power It is possible the unit overheated. Wait for the unit to cool down and try again.
-
Page 2: Assembly Instructions
QUICK REFERENCE GUIDE Griddler Deluxe ® ASSEmBLy INSTRUCTIONS Place base on a clean, flat surface where you intend to cook, with the controls directly in front of you. To insert the cooking plates: 1. Choose the side(s) you intend to cook on. The two cooking plates each have a grill and a griddle side. - Page 3 GRIddLER dELUXE pOSITIONS ® STORAGE Position – Upper plate/cover rests flat on the lower plate/base and cover height adjuster is in Lock position. PREHEAT Position – Upper plate cover rests flat on the lower plate/base and cover height adjuster is in Unlock position. OPEN COOKING Position – To cook on lower plate only: Lift the handle so upper plate/cover is vertical. Plate does not “float” in this position. CLOSED COOKING Position – To contact grill or panini press: Start with unit in Open Cooking position. Lower top carefully until plate contacts food. Hinge will automatically release the plate, allowing it to “float” and rest evenly on food. To Top Melt: Start with unit in Open Cooking position. Wearing an oven mitt, press down slightly on front of upper plate/cover to release hinge, allowing plate to “float.” Lower it to close to the desired height, then slide the cover height adjuster into a notch to set...
-
Page 4: Cleaning And Care
OpERATING THE GRIddLER dELUXE (CONTINUES) ® • W hen the plate(s) reach the SEAR temperature, the LED light around the UPPER SEAR and/or LOWER SEAR button(s) will turn green and will flash ten times to allow enough time to put the food on the plate(s). • A fter 10 seconds, the green light will stop flashing and the upper and/or lower plates will sear for 2 minutes. • W hen the sear cycle has finished, the LED light around the UPPER SEAR and/or LOWER SEAR button(s) will go off and the unit will adjust to the temperature(s) selected on the corresponding temperature knobs. • T o cancel SEAR, press the SEAR button(s) again. The LED light(s) will turn off and the unit will adjust to the temperature(s) selected on the corresponding temperature knobs. Cleaning and Care Make sure the plates have cooled completely for at least 30 minutes. Use the cleaning tool to remove any leftover food from the plates. Dispose of any grease from the drip tray once cooled. Press the plate release buttons on the right side of the unit to remove the plates from the housing. The plates, drip tray, and cleaning tool can be cleaned by hand or on the top shelf of the dishwasher. The housing base and control panel can be wiped clean with a soft, dry cloth. STORAGE 1. Wrap the power cord around the cord storage clips at the back of the base.
