- Page 1 SR-1602 FEEDBACK SUPPRESSOR N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
CONTROLS AND FUNCTIONS FRONT PANEL 1.- INPUT LEVEL: gain control of the input signal. 2.- PROCESS ON-OFF: switch to activate or deactivate audio signal processing in order to suppress feedback. 3.- OUTPUT LEVEL: gain control of the output level. 4.- MIC IN-LINE IN: input, line or microphone signal level selector. 5.- PHANTOM: 48 V phantom power supply selector for condenser microphones. -
Page 5: Panel Posterior
INSTRUCTIONS FOR USE - The SR-1602 is a feedback suppressor based on the processing and analysis of content in the frequency of the input audio signal and the elimination of components in the frequency, which produce the feedback or link effect, through 12 high precision parametric notch filters per channel. - Page 6 Activating and deactivating this control, you can easily check if the feedback suppressor is deleting feedback. 5.- You can choose the feedback detection sensitivity with the SENSITIVITY control wheel. There are 15 sensitivity levels. You can choose the best one for your needs. To start with it is best to choose an intermediate position.
-
Page 7: Block Diagram
BLOCK DIAGRAM CONNECTION The feedback suppressor SR-1602 can be incorporated into a P.A. system in many ways thanks to its accepting microphone or line signals and that it has phantom power supply available. Example of a microphone connection to the SR-1602 input... -
Page 8: Specifications
Example connection of the SR-1602 between the mixer and the power amp SPECIFICATIONS SR-1602 CHARACTERISTICS Feedback suppressor. 12 adaptive notch filters per channel. 15 sensitivity and bypass levels. Parameters and attenuation of fixed or variable filters. Stereo microphone input with phantom or line power supply. -
Page 9: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
