- Page 1 SR-1590 ACOUSTIC FEEDBACK SUPPRESSOR N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
- Page 3 The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
-
Page 4: Controls And Functions
DESCRIPTION The model SR-1590 is an acoustic feedback suppressor using frequency displacement. It efficiently removes acoustic feedback or links by using frequency displacement. Due to it being easy to use it is suitable for all types of systems with multiple microphone inputs, such as conference systems, congresses, board meetings, etc. -
Page 5: Installation And Connection
When not using the mixer disconnect the power supply source from the mains to avoid using electricity. CONNECTION DIAGRAM The model SR-1590 acts as a feedback suppressor for an external source connected via a balanced XLR mic. Level input or an unbalanced RCA line level input. - Page 6 ACOUSTIC FEEDBACK DETECTION The main mission of the SR-1590 is to remove links or acoustic feedback in the inputs connected to it. Acoustic feedback is produced when the sound reproduced by the speakers is picked up on again by the microphone, to be amplified again.
-
Page 7: Specifications
SPECIFICATIONS SR-1590 CHARACTERISTICS Feedback suppressor. Frequency displacement 5Hz ±1Hz. Mono mode. RESPONSE 20-20 000 Hz without feedback suppression. 150-15 000 Hz with feedback suppression INPUTS 1 balanced mic,XLR 5,000Ω 2.5 mV 1 unbalanced line, RCA 5,000Ω 1 V OUTPUTS 1 balanced mic., XLR 600 Ω100mV 1 unbalanced line, RCA 600Ω... -
Page 8: Declaration Of Conformity
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
