Box Edge Plus
Steel Shelving
®
Installation Instructions
––––––––– IMPORTANT –––––––––
RETAIN THIS MANUAL
PRODUCT LIABILITY INFORMATION
FOR FUTURE REFERENCE
Read all instructions before proceeding with installation or shelf loading.
Vital product information pertaining to proper set-up, safe loading and cau-
tions are included. Failure to follow these instructions may cause shelving
02-50000-00C
failure which may result in personal injury and/or property damage.
December 2002
- 1 -
Advertisement
Table of Contents
Related Manuals for Borroughs Box Edge Plus
Summary of Contents for Borroughs Box Edge Plus
- Page 1 Box Edge Plus Steel Shelving ® Installation Instructions ––––––––– IMPORTANT ––––––––– RETAIN THIS MANUAL PRODUCT LIABILITY INFORMATION FOR FUTURE REFERENCE Read all instructions before proceeding with installation or shelf loading. Vital product information pertaining to proper set-up, safe loading and cau- tions are included.
-
Page 2: General Instructions
1750 lbs. nent, please call our Customer Service Department at 42" x 32" 300 lbs. 650 lbs. 1000 lbs. 800-748-0227 and ask for the booklet "Box Edge Plus 36" x 36" 400 lbs. 1600 lbs. ® 42" x 36" 450 lbs. -
Page 3: Warranty
If a Borroughs product fails to perform because of a manufacturing defect, of all other warranties, either expressed or implied. Borroughs will examine it. If found defective, it will be repaired or replaced at our This warranty give you specific legal rights; you may also have other rights option. - Page 4 OPEN TYPE SHELVING 1/4-20 x 3/4" Hex Head Cap Screw STEP I SWAY BRACE ASSEMBLY and Hex Nut After the material has been distributed to the proper location, assemble all sway braces by loosely bolting two matched pieces together at the center. Assemble side sway braces with 1/4-20 x 3/4"...
- Page 5 Back Sway Brace STEP 4 SINGLE ROW - SINGLE FACE ASSEMBLY In assembly of a single row - single face, begin with a row end upright assem- bly, a back sway brace and an intermediate upright assembly. The brace bolts to the row end and the intermediate at the same level and spacing as the Row End previously installed side braces.
- Page 6 STEP 7 SECTION LEVELING When required, level sections with shims to cause each upright assembly to be plum within 1/10 inch per foot of height, up to and including 10' high units. For units higher than 10', maximum out-of-plumbness should not exceed 1". FAILURE TO LEVEL SECTION COULD RESULT IN SHELVING COLLAPSE, PERSONAL INJURY AND/OR COMMODITY LOSS.
- Page 7 STEP 3 SINGLE ROW - SINGLE FACE 1/4-20 x 5/8 Hex Head ASSEMBLY Cap Screw (Grade 5) and Hex Nut In assembly of a single row - single face, begin with a row end - closed upright assembly, a back and an intermediate - closed upright assembly. The back bolts inside the angle post flanges, on both the row end and the intermediate, at the fourth hole from each end and at two medial* points.
-
Page 8: Major Accessories
STEP 6 SECTION LEVELING Where required, level sections with shims to cause each upright assembly to be plum within 1/10" inch per foot of height. FAILURE TO LEVEL SECTIONS COULD RESULT IN SHELVING COLLAPSE, PERSONAL INJURY AND/OR COMMODITY LOSS. STEP 7 TIGHTEN ALL BOLTS Shims Front and/or Rear... - Page 9 SHELF DIVIDERS - FULL HEIGHT Snap Fastener Beaded Edge Install beaded edge toward front. Fasten in place with a snap fastener through hole in divider flange and hole in shelf, both top and bottom. When one divider is installed directly above or directly below another divider, one fastener per hole will hold both dividers.
- Page 10 Side Brace FOR UNITS OVER 99" HIGH Light Loading For rigidity, Borroughs recommends that one pair of sway braces be installed in each open end and open back. Sway brace height is as shown in Figure 6. Figure 6A and 6B are an end and an intermediate, respectively.
-
Page 11: Hardware Requirements
HARDWARE REQUIREMENTS Pieces Pieces Pieces Part Name Hardware Included Req'd. Part Name Hardware Included Req'd. Part Name Hardware Included Req'd. 1/4-20 x 5/8 HHMS Gr. 5 Divider Clip (nylon) Hardware Pack #48 includes: Angle Post Shelf Divider Sliding Door 1/4-20 Hex Nut (14761-000) Door Pulls (Plated) Std. - Page 12 © ICBO and Borroughs assume no responsibility for the accuracy or the completion of summaries provided herein. All areas of the United States have been zoned seismically. Each zone indicates the anticipated intensity or severity of a seismic occurrence within that region.
