Summary of Contents for Alula RE703
- Page 1 Doorbell Camera Quick Start Guide SAVE THIS MANUAL FOR FUTURE REFERENCE...
-
Page 2: Quick Setup
Quick Setup Power Kit Installation Doorbell Mounting Doorbell Setup... -
Page 3: What's In The Box
What's in the Box Mounting Plate (x3) Pick the one for best Doorbell (x1) surveillance angle. Faceplate (x3) Pick the one that Screwdriver (x1) best matched your home from three faceplates. Plate Foam (x1) Stabilize the mounting plate when installing it in the Drill Bit (x1) rough surface. - Page 4 Power Kit Installation •If you have the mechanical chime in your home, start from Step 1 here. •If you have the electronic chime in your home, please refer to its manual for detailed operations. •If you do not have any chime, skip power kit installation and follow the Option B in page 5.
-
Page 5: Wiring Overview
Insert the existing chime wire and the other Connect the wire harness to the chime's end of the wire harness into the wire terminals named TRANS and FRONT. connector and twist it tightly. Repeat this step with the other chime wire. Wire Connector Chime Wire Wire Harness... - Page 6 Doorbell Mounting (Optional) Paste the plate foam to the Shut off the electricity at the breaker that mounting plate. controls doorbell's circuit. Use the plate foam when your wall is uneven. Drill holes according to drill points Insert the mini-level into the mounting plate and and insert anchors.
- Page 7 If power kit is installed, follow Option A; If not, follow Option B. Option A Connect doorbell with your existing doorbell wires. U-Shaped Wire Fixing Screw Option B Connect the fuse wire with your existing doorbell wire. U-Shaped Wire Fixing Screw...
- Page 8 If yes, proceed to doorbell setup. Doorbell Setup Add to Alula app. - On the Cameras tab, tap “+” on the upper-right corner to go to the scan QR code page. Scan the QR code on the device or the cover of this manual when the indicator flashes blue.
-
Page 9: Sd Card Management
Put the faceplate back and insert two security screws into the bottom of the doorbell to secure the faceplate. Security Screw Appendix Basics SD Card Management micro SD Terminals Mounting Holes Card Slot Reset Button Hold for 5s to reset and enter to AP mode.
