Pcb Layout; Parts List - Linear DC1957A Demo Manual

DEMO MANUAL DC1957A

PCB LAYOUT

Top Copper

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 U1
Hardware: For Demo Board Only
2 4 C1-4
3 16 E4-19
4 6 E1-3, E20-22
5 2 JP6-7
6 10 JP1-5, JP8-12
7 12 JP1-12
8 10 R1-R10
4
PART DESCRIPTION
I.C., LTM2892CY-S
CAP., TANT 4.7μF 10V 20% 0805
TURRET, 0.065"
TURRET, 0.095"
2mm SINGLE ROW HEADER, 2 X 1 PIN
2mm SINGLE ROW HEADER, 3 x 1 PIN
2mm SHUNT
RES., CHIP 100Ω 5% 1206
Bottom Copper
MANUFACTURER/PART NUMBER
LINEAR LTM2892CY-S#PBF
NICHICON F921A475MPA
MILL-MAX 2308-2-00-80-00-00-07-0
MILL-MAX 2501-2-00-80-00-00-07-0
SAMTEC TMM-102-02-L-S
SAMTEC TMM-103-02-L-S
SAMTEC 2SN-BK-G
AAC CR18-101JM
dc1957af
