6" Diesel Trash Pump
Description
This trash pump is heavy duty, centrifugal, engine driven, self-priming (to 20 ft. lift), and transportable unit. Pump is equipped with precision lapped mechanical shaft
seal to reduce the likelihood of leakage, and a clog resistant impeller capable of handling solids up to 3" in spherical diameter. Units are used to handle water
containing stones, sticks, mud, and other solids (up to 20% by volume). O-ring sealed flange connection to provide leak-free low maintenance operation. Suction
flange male NPT threaded for direct coupling to a standard NPS hose connector with rubber gasket. Liquid temperature range is 40º to 180º F (4º to 82º C). Maximum
casing pressure if used in a flooded suction application is 50 psi. For use with nonflammable liquids that are compatible with pump component materials.
All models come equipped with a 12V electric
starting system including automotive type 12V
battery and cables. A fully plumbed and
mounted 16 gallon fuel tank is standard. All
units equipped with a digital tachometer/hour
meter.
Pump and engine are mounted on an easy
maintenance sliding frame assembly. Frame
can be mounted to transport trailer equipped
with pneumatic tires, lighting system, rear
stabilizer jacks, and 1-7/8" diameter ball mount
tongue hitch. Trailer meets DOT requirements
and is supplied with certificate of origin and VIN
number. Check state and local requirements to
register trailer/pump for highway towing.
Specifications
Suction Inlet . . . . . . . . . . . . . . . 6" NPT (male)
Discharge outlet . . . . . . . . . . 6" NPT (female)
Engine
5583-D6 . . . . . . 26 HP 3LC950D Diahatsu
Battery . . . . . . . . . . . . . . 12 volt, BCI size 24
. . . . . . . . . . . . . . . . . . . . 500 min CCA @ 0ºC
Basic Construction:
Cast aluminum with cast iron volute, suction
flange and discharge manifold. Viton silicon
carbide shaft seal, Buna O-rings,
Buna/Neoprene suction check valve.
Unpacking
Refer to Repair Parts Illustration and Repair
Parts List to aid in identifying parts. Unpack and
separate all pump components from
shipping/packaging materials, making sure all
parts are accounted for. Retail all manuals for
reference.
Package should contain:
1.
Pump and engine completely assembled
and mounted to rail assembly.
2.
Trailer assembled except tail lights to
prevent damage during shipping.
5583-250-00
3.
Manuals included:
Specifications Information & Repair Parts
Manual, Operating Instructions &
Maintenance Manual, trailer
instruction/owner's manual, engine
instruction/owner's manual and
tachometer/hour meter instruction sheet.
Assembly
Tail light assembly installation:
1.
Install driver side tail light assembly with
license plate holder to trailer frame rail
with 2 carriage bolts and nuts provided.
2.
Connect red wire (light) to yellow wire
(trailer) with wire nut, connect two black
wires (light) to yellow/brown wire (trailer)
with wire nut.
3.
Install passenger side tail light assembly
to trailer frame rail with 2 carriage bolts
and nuts provided.
4.
Connect red wire (light) to brown wire
(trailer) with wire nut, connect two black
wire (light) to green wire (trailer) with wire
nut.
NOTE: Follow all recommendations in General
Operating Instruction and Maintenance Manual
provided with this pump. In addition, follow the
specific recommendations that follow:
Installation:
Trailer mounted pump:
To avoid trailer tipping, set
rear trailer stabilizer jacks
before removing trailer from vehicle hitch.
1.
Always set trailer tongue stand and rear
trailer stabilizer jacks before unhooking
trailer hitch from vehicle tow ball.
2.
Make sure pump and trailer are level and
trailer wheels are blocked to prevent
movement during operation.
5583-D6
Frame mounted pump:
3.
Pump frame must be supported on a level
firm surface. Anchoring pump frame to
support surface is required to prevent
movement during operation. A vibration
dampening mounting system should be
employed. Allow sufficient clearance
around pump frame to perform routine
maintenance.
All installations:
4.
Suction line should be as short and direct
as possible, have a constant slope up to
the pump's suction port, and line diameter
must match suction port diameter. If hose
is used, it must be non-collapsible.
5.
Check condition of suction hose gaskets
before installation. Weak, worn, leaking
gaskets will allow an air lead at suction
connection. If suction connection leaks
air, the pump will not prime.
6.
Supports must be used to carry the weight
of the suction and discharge lines. The
pump should not be used to support the
entire weight of the suction and discharge
lines. Damage/breakage of pump ports
may occur if lines are not supported.
7.
If a check valve or collapsible hose is
used on discharge, a means of venting air
from the pump discharge manifold is
required during the priming cycle. If air
cannot escape from casing, the pump will
not prime.
LIFTING EYES
Pump frame is equipped with four 3/8-16x1" ID
lifting eye bolts (Ref. No. A6). Eye bolts
provided for lifting of pump frame on and off of
transport trailer and to lift complete pump/trailer
assembly. Eye bolts rates for lifting pump,
frame and trailer only.
Remove suction and
discharge lines and drain
10/2006
