AMT 5150-96 Specifications Information And Repair Parts Manual

Specifications Information and Repair Parts Manual
Please read and save this Repair Parts Manual. Read this manual and the General Operating Instructions carefully before attempting to assemble, install, operate
or maintain the product described. Protect yourself and others by observing all safety information. The Safety Instructions are contained in the General Operating
Instructions. Failure to comply with the safety instructions accompanying this product could result in personal injury and/or property damage! Retain instructions
for future reference. AMT reserves the right to discontinue any model or change specifications at any time without incurring any obligation.
©2012 American Machine & Tool Co., Inc. of PA, A Subsidiary of The Gorman-Rupp Company, All Rights Reserved.
Periodic maintenance and inspection is required on all pumps to ensure proper operation. Unit must be clear of debris and sediment. Inspect for leaks and loose bolts. Failure to do so
voids warranty.
High Flow Drum Pump
Aluminum Model
DESCRIPTION
This High Flow Hand-Crank Drum Pump is self-priming. It is used for dispersing and transferring lubricating oil, antifreeze (ethylene-glycol), fuel oil, gasoline and
other noncorrosive, non-abrasive liquids compatible with pump component materials*.
(*) Always refer to a chemical resistance chart to confirm compatibility. Not rated for food products.
UNPACKING
Inspect carefully for any damage that may have occurred during transit. Check
for loose, missing or damaged parts. Transit damage claims should be made
to the shipping company.
SPECIFICATIONS
Flow...................................................................................27 GPM at 120 RPM
Max. Liquid Temperature..............................................................160º F (71º C)
Mounting...................................................................................2" Bung Adapter
Inlet.........................................................................................................1" NPT
Outlet.......................................................................................................1" NPT
Spout...............................................................................................Plated Steel
Pump Housing............................................................................Cast Aluminum
Rotors.........................................................................................................Steel
Fasteners (non-wetted)...................................................................Plated Steel
Seals..........................................................................................Nitrile (Buna-N)
Suction Strainer...................................................................................#60 Mesh
Weight ..................................................................................................11.3 lbs.
GENERAL SAFETY INFORMATION
It is the responsibility of the user to operate the pump in conformance
with OSHA rules for dispensing liquids. Pump containers should be
grounded when using with flammable liquids to avoid static electricity.
Pump should be washed out before usage since processing lubricants
could contaminate the fluid.
1. When using a hand pump (especially when pumping flammable,
combustible, or hazardous liquids) follow all electrical and safety codes,
as well as the United States Occupational Safety and Health Act (OSHA),
most recent National FIre Protection Association, Inc. † (NFPA) Code
30 (Flammable and Combustible Code), NFPA 56A (Standard for use of
Inhalation Anesthetics), NFPA 77 (Static Electricity), NFPA 78 (Lighting
Protection Code), NFPA 80 (Standard Method of Fire Test of Building
Construction), NFPA 704 (Identification of the Fire Hazards of Material(s),
other NFPA codes, local codes and ordinances, as needed in a particular
application.
(†)Any of the NFPA Codes can be obtained from National Fire Protection
Association, Inc., Batterymarch Park, Quincy, MA 02269, telephone 1-800-
344-3555. Write or call for listing and prices.
5150-254-00
2. Know the pump application, limitations and potential hazards. The
WARNING statements indicate potentially hazardous conditions for
the operator or equipment. TAKE NECESSARY STEPS TO PROTECT
PERSONNEL AND EQUIPMENT. Pump should only be used with
liquids compatible with pump component materials. Consult PUMP
CHEMICAL COMPATIBILITY CHART and PUMP SPECIFICATIONS.
Also, the chemical supplier should be consulted regarding any questions
of chemical compatibility, proper and safe use and handling of chemical
.Misapplication of pump or use of non-compatible liquids will void warranty.
In order to properly use this product familiarize yourself with this pump
and also with the liquid (chemical, etc.) that is going to be pumped
through the unit. Although this pump is suitable for many liquids, it is not
suitable for all liquids!
3. Pumping hazardous, flammable or combustible liquids should only be
done in buildings, rooms or areas suited for this purpose (See NFPA 30,
NFPA 78, NFPA 80, NFPA 251, NFPA 704, other suitable NFPA codes,
OSHA, insurance companies, local codes and ordinances).
When filling cans, drums, etc. with combustible or flammable liquids, both
container pumping from and container pumping to, should be bonded
and grounded to dissipate possible accumulations of static electricity
and minimize sparks caused by static electricity (refer to NFPA 77 for
specifics and further details).
Removal of outer garments in work areas where there may be flammable
or explosive liquids, which are ignitable with low electrical energy can be
fatal and/or cause property damage (refer to NFPA 56A, and NFPA 77 for
further details).
4. The WARNING and instructions for gasoline that follow pertain not only to
gasoline, but to any flammable, combustible or hazardous fluid.
Gasoline is a highly flammable fuel. The improper use, handling or
storage of gasoline can be dangerous. Prevent accidents by following
these safety rules:
• Use gasoline only as fuel, never as a cleaning fluid.
• Use only an approved container to hold or store gasoline. Never
store gasoline in familiar containers such as milk or soda pop
bottles.
1
5150-96
11/2012
