Eyemax IB-6335MV Manual

INFRARED BALL DOME CAMERA
3700-8384C [67]
Effio-E
TM
700TVL (960H) DSP
FEATURES
1/3 INCH SONY EXVIEW HAD CCD II
High Resolution / High Sensitivity
Upgraded Weather proof Housing
0 Lux at IR On (IR LED 35 pcs)
External Zoom & Focus Control
Day & Night / SMART IR / Easy Installation
DC Auto IRIS Manual V/F Lens 2.8~12mm
DC Auto IRIS V/F Lens 2.8~12mm
SPECIFICATION
CHIPSET Effio-E TM
700 TV Line
Resolution
Sensor 1/3 INCH SONY EXVIEW HAD CCD II
Total Pixels 1020(H) x 508(V ) 520K pixels (NTSC) ｜ 1020(H) x 596(V ) 610K pixels (PAL)
Effective Pixels 976(H) x 494(V ) 480K pixels (NTSC) ｜ 976(H) x 582(V ) 570K pixels (PAL)
Scanning System 2:1 Interlace
S/N (Y signal) More than 52 dB (AGC Off)
Frequency Horizontal: 15.734KHz / Vertical: 59.94Hz (NTSC) ｜ 15.625KHz / Vertical: 50.00Hz (PAL)
CVBS: 1.0Vp-p / 75ohm
Video Output
0 Lux at IR On
Min.Illumination
White Balance ATW
AUTO (1/60sec ~ 1/100,000sec) (NTSC)
Electronic shutter speed
AUTO (1/50sec ~ 1/100,000sec) (PAL)
Day & Night AUTO
Language ENGLISH
Operating Temperature / Humidity -10'C ~ +50'C / 30% ~ 80% RH
Storage Temperature / Humidity -20'C ~ +60'C / 20% ~ 90% RH
DC12V
Power
( AC24V / DC12V DualPower : option )
Above specifications may be changed without any notice.
