Eyemax DO-632V Manual

VANDALPROOF DOME CAMERA
3700-8364A [66]
Effio-E TM
700TVL (960H) DSP
FEATURES
1/3 INCH SONY EXVIEW HAD CCD II
High Resolution (700 TVL) / High Sensitivity
Upgraded Waterproof Housing (IP68 rating)
0.1 Lux at af 1.2
OSD Controlled / Motion / Privacy
True Day & Night / 2DNR / BLC / ATR
Easy Installation / 3Axis
Lens Option : DC Auto IRIS V/F Lens 2.8~12mm
DC Auto IRIS & TDN V/F Lens 2.8~12mm
SPECIFICATION
CHIPSET Effio-E TM
Resolution 700 TV Line
Sensor 1/3 INCH SONY EXVIEW HAD CCD II
Total Pixels 1020(H) x 508(V ) 520K pixels (NTSC) ｜ 1020(H) x 596(V ) 610K pixels (PAL)
976(H) x 494(V ) 480K pixels (NTSC) ｜ 976(H) x 582(V ) 570K pixels (PAL)
Effective Pixels
Scanning System 2:1 Interlace
S/N (Y signal) More than 52 dB (AGC Off)
Frequency Horizontal: 15.734KHz / Vertical: 59.94Hz (NTSC) ｜ 15.625KHz / Vertical: 50.00Hz (PAL)
Video Output CVBS: 1.0Vp-p / 75ohm
0.1 Lux at 1.2
Min.Illumination
White Balance ATW / PUSH / USER1 / UESR2 / ANTI CR / MANUAL / PUSH-LOCK
Electronic
AUTO / MANUAL (1/60sec ~ 1/100,000sec) (NTSC) ｜ (1/50sec ~ 1/100,000sec) (PAL)
shutter speed
O.S.D Built-in
Backlight Compensation OFF, BLC,HLC, Selectable
ATR ON / OFF (LEV EL ADJUSTABLE)
2DNR (2D Digital Noise Reduction) ON / OFF (LEV EL ADJUSTABLE)
Day & Night Auto (Day <--> Night TIME Change) , COLOR , B/W
Privacy OFF / ON (8 Zone) [ Motion on : 4 Zone ]
Motion Detection OFF / ON ( 4 Z one)
Image Conversion
ON / OFF
Language
ENGLISH, JAPANESS, GERMAN, FRENCH, RUSSIAN, PROTUGUESE, SPANISH
Operating Temperature / Humidity -10'C ~ +50'C / 30% ~ 80% RH
Storage Temperature / Humidity -20'C ~ +60'C / 20% ~ 90% RH
DC12V
Power
( AC24V / DC12V DualPower : option )
Above specifications may be changed without any notice.
