Summary of Contents for Victorio Johnny Apple Peeler VKP1010

  • Page 2 Your Johnny Apple Peeler™ by VICTORIO® should include the following, depending on the model. Thumb Lever VKP1010 Handle Arm (Suction Base) Driveshaft Fork Peeling Blade Handle Screw Lock Lever Coring/Slicing Handle Blade Peeling Arm VKP1011 (Clamp Base) Copyright © 2017 VICTORIO® Kitchen Products. All Rights Reserved.
  • Page 3 CONGRATULATIONS! You now own the world’s finest apple and potato peeler, the Johnny Apple Peeler™ by VICTORIO®. It’s designed to save you time, ef- fort, and money by performing several tasks at once. Before plunging right in and peeling a bushel of apples or a bag of potatoes, you will want to get acquainted with your peeler.
  • Page 4 Mounting to a suitable surface: Before using, the peeler needs to be properly secured to a suitable surface so it will stay firmly in place during use. Otherwise, the peeler will not work properly. VKP1010 Suction Base model: The suction mount must be used with a smooth and non-porous surface.
  • Page 5 Misaligned or unsecured blades will damage the peeler. This video shows how to properly align, adjust, and secure the blades http://victorio.info/apple-peeler-video.html Align the coring/slicing blade: The fork should be able to pass through the center of the blade with- out touching the sides.
  • Page 6 Adjust peeling blade: The peeling blade works best when adjusted to about 1/8 inch past the head of the peeling arm. To adjust the peeling blade, loosen the wing-nut 1/2 turn. The blade can be moved forward to remove more peel, or backward to remove less peel.
  • Page 7 Place apple on fork: • Press the thumb lever (see illustration on bottom of page 5). and pull the driveshaft away from the coring/slicing blade. Pull until the fork is as far away from the coring/slicing blade as possible. • Center apple stem end first in front of the fork.
  • Page 8 Peeling only: • Peeling apples and potatoes is quick and easy with the Johnny Apple Peeler™ by VICTORIO®! • Loosen the wing-nut that holds the coring/slicing blade in place. Remove the blade or simply turn it out of the path of the apple or potato.

  • Page 9: Cleaning And Care

    Cleaning and care: • When cleaning the entire unit, hand washing is recommended. • After washing, dry all parts thoroughly by hand. Do not allow to air dry. • Peeling and coring/slicing blades can be washed in a dishwasher. • A drop of vegetable oil on the moving parts will insure smooth operation for next use.
  • Page 10 The first step to restaurant-style hash browns is cutting them to shoe- string thickness. No more scrubbing potatoes and knuckles across the graters. The Johnny Apple Peeler™ by VICTORIO® makes cutting shoestring potatoes nearly effortless. 1. Remove the coring/slicing blade from the path of the shaft.
  • Page 11 TROUBLESHOOTING GUIDE PROBLEM SOLUTION Peeler is taking off too much flesh with Adjust the peeling blade to remove the peel. less flesh with the peel. See page 6 for instructions. Peeling blade is digging in/gouging Peeling arm and/or peeling blade fruit when first starting to peel.
  • Page 12 • Damage to the product due to accident, misuse, abuse, negligence, or if the appliance has been altered in any way. VICTORIO® Kitchen Products 1804 Sandhill Rd Orem UT, 84058 By Phone: 866-257-4741 By Email: Help@VICTORIO.info www.VICTORIO.info © Copyright 2017 VICTORIO® Kitchen Products, Inc. All rights reserved.
