Mid-Century Spindle Conversion Bed
A
(Pre-attached to large bolts)
1
Attach 1 leg A and 1 leg B to 1 side panel/headboard as shown. Using a small Allen wrench, secure each leg with 2 large
bolts, 2 spring washers and 2 flat washers as shown. Repeat steps for footboard. Do not over tighten the bolts.
headboard
assembly
2
With assistance of another adult, attach headboard assembly to 1 side rail with 3 large bolts, 3 spring washers and 3
flat washers as shown. Secure bolts with a small Allen wrench.
Assembly Instructions
A
A
foot rail
800.967.6696 | crateandbarrel.com
side panel/
headboard
B
B
(Pre-attached to large bolts)
