Operating Instructions & Parts Manual
Model Number
ATD-7344A
ATD-7345A
Model ATD-7344A
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
© Jan 2018
Aluminum Plus
Service Jack
WARNING
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use an identical pair of
adequately rated jack stands.
Visit us at www.atdtools.com
Capacity
1.5 Ton
2.5 Ton
Model ATD-7345A
ATD7344A-ATD7345A_M0_012018
Advertisement
Table of Contents
Related Manuals for ATD Tools ATD-7344A
Summary of Contents for ATD Tools ATD-7344A
- Page 1 1.5 Ton ATD-7345A 2.5 Ton Model ATD-7344A Model ATD-7345A This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
-
Page 2: Safety And General Information
SAFETY AND GENERAL INFORMATION Save these instructions. You will need the manual for the safety warinings and precautions, assembly instructions, operating and maintenance procedures,parts list and diagram. Keep your invoice with this manual. Write the invoice number o the inside of the front cover. Keep the manual and invoice in safe and dry place for future reference. For your safety, read, understand, and follow the information provided with and on this device before using. -
Page 3: Product Description
Min. Max. Saddle Model Capacity Jack Size (L x W x H) Handle Length Weight Height Height Diameter ATD-7344A 1.5 Ton 21-3/4" x 9-3/8" x 5-5/8" 3-1/2" 14" 3-7/8" 37-1/4" 32.9 lbs ATD-7345A 2.5 Ton 26-3/8" x 11-7/8" x 6-1/8"... -
Page 4: Operation
PREPARATION Unpacking When unpacking, check to make sure the following parts are included. Refer to the parts lists and Assembly Drawings for more details. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact Customer Service. -
Page 5: Maintenance
MAINTENANCE General Periodically lubricate the Jack as described below. 1. Lubricate the joints and Ram with light oil as needed. 2. Remove Handle and grease the lower end of the Handle where it rotates in the Handle Socket. 3. Oil all lift arm linkages, front wheels, and rear casters. 4. - Page 6 5. Replace the Oil Plug. 6. Purge air from the hydraulic system as previously described. 8. Contact the local Hazardous Wast Disposal authority for proper oil disposal instructions. 9. Maintain tools with care. Keep tools sharp and clean for better and safer performance. Follow instructions for lubricating and changing accessories.
-
Page 7: Replacement Parts
REPLACEMENT PARTS Available Parts: Please refer to the Parts drawing when ordering parts. Not all components of this kit are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, give model number, serial number and description. Call your distributor for current pricing. Figure 3 - Replacement Parts Illustration (ATD-7345A shown) Please see the chart on the next page for part numbers. - Page 8 When ordering parts, give model number, serial number and description. Call your distributor for current pricing. Part No. Item Description ATD-7344A ATD-7345A 0002-02-3 0002-02-3 Saddle Pad...
-
Page 9: Troubleshooting
TROUBLESHOOTING Symptom Possible Causes Corrective Action Jack will not lift load at 888-332-6419 Jack will not Bleeding/Venting Trapped... -
Page 10: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, ATD Tools, Inc. will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship, or which fails to conform to any implied warranty not excluded hereby.
