- Page 1 P L E A S E T H I N K B E F O R E Y O U P RI N T SMART Audio™ CAS-340 and CAS-360 Classroom Amplification System Installation Guide...
-
Page 2: Serial Number
SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART. -
Page 3: Table Of Contents
Installing the room module ................10 Installing the control unit ................13 Installing the microphone charging cradle............. 17 Integrating your SMART Audio system with your SMART Board interactive whiteboard system ............. 19 Hardware environmental compliance ................21 Waste Electrical and Electronic Equipment regulations (WEEE Directive) ... 21 Restriction of Certain Hazardous Substances (RoHS Directive) .... - Page 4 CON T ENT S...
-
Page 5: Planning Your Installation
Chapter 1 Planning your installation Product components This guide describes the installation of the following SMART Audio classroom amplification system components: • Control unit – Mounting plate – Cable cover – Power cable • Room module – Mounting plate –... -
Page 6: See Page
NOTE Your SMART Audio system doesn’t include Cat 5e cable or speaker wire, unless you order it specifically with your classroom amplification system. You can purchase these wires and cables from most professional installers. - Page 7 CH AP TE R 1 Planning your installation Choosing a location for the control unit Install the control unit on the wall at the front of the room where the presenter can easily access it. Select a location that is within 2.4m (8') of a power socket and within 15.2m (50') of cable distance from the room module.
- Page 8 CH AP TE R 1 Planning your installation SMART Audio system cabling diagram Speaker wire (See Room module page 5) (See page 10) Ex pa n sio n S en sors N.C . C OM N.O. P A G I NG...
-
Page 9: Installing Your Smart Audio System
Chapter 2 Installing your SMART Audio system Installing speaker wires and Cat 5e cables Run the speaker wires to the speakers and run the Cat 5e cable between the control unit and room module before you begin installation. If you want to place the wires and cables out of sight, run the cables in the walls and ceiling. - Page 10 2. Pull an RCA cable from the room module location to each expansion sensor location. To install audio cables from your SMART Board interactive whiteboard system If you have a SMART Board interactive whiteboard system, pull audio cables from the audio out connectors on your projector to the control unit location.
-
Page 11: Installing Ceiling Speakers
CH AP TE R 2 Installing your SMART Audio system Installing ceiling speakers For each of the four speakers, use the ceiling speaker cut-out template to cut a hole in a ceiling tile, and then assemble the ceiling tile bridge, secure the speaker to the ceiling tile and replace the tile. - Page 12 CH AP TE R 2 Installing your SMART Audio system 3. Slide the ceiling tile and tile bridge onto the speaker. 4. Turn the ceiling speaker clamps so that they are perpendicular to the speaker.
-
Page 13: Installing Wall Speakers
CH AP TE R 2 Installing your SMART Audio system Installing wall speakers For each of the four speakers, install the wall speaker bracket on the wall and then attach the speaker to the bracket. To install the wall bracket on the wall 1. -
Page 14: Installing The Room Module
CH AP TE R 2 Installing your SMART Audio system Installing the room module Install the room module mounting plate on the ceiling or on a ceiling tile, and then attach the room module and the cable cover to the mounting plate. - Page 15 CH AP TE R 2 Installing your SMART Audio system 3. Screw the mounting plate to the ceiling with the screws and drywall anchors included. Attaching the room module to the mounting plate Attach the room module to the mounting plate and then connect the wires, cables and safety tether.
- Page 16 NOTES – For more information on customising the 6-12 V DC input, the relay output and the way pages play over the SMART Audio system, see the SMART Audio CAS-340 and CAS-360 Classroom Amplification System User’s Guide (smarttech.com/kb/155322). – The Relay output has 3 states: NC (normally closed), COM (common) and NO (normally open).
-
Page 17: Installing The Control Unit
CH AP TE R 2 Installing your SMART Audio system Installing the control unit Install the mounting plate and then attach the control unit and cable cover to the mounting plate. Select a location on the wall that is within 2.4m (8') of a power socket. - Page 18 3. Connect the included USB cable from the control unit to your computer. 4. If you have a SMART Board interactive whiteboard system, connect the RCA cable (with two connectors on each end) from your projector to the Aux In 1 connectors.
- Page 19 CH AP TE R 2 Installing your SMART Audio system To install the power supply 1. Hold the power supply mounting plate against the wall where you plan to install it and then mark the anchoring holes on the wall with a pencil.
- Page 20 CH AP TE R 2 Installing your SMART Audio system 6. Push the cables into the cable slots in the mounting Cable slot bracket. Cable slot 7. Attach the power supply cover to the bracket.
-
Page 21: Installing The Microphone Charging Cradle
CH AP TE R 2 Installing your SMART Audio system Installing the microphone charging cradle You can install the microphone charging cradle on the wall or place it on a table. If you’re mounting the charging cradle on the wall, install its mounting plate, and then attach the charging cradle to the mounting plate. - Page 22 CH AP TE R 2 Installing your SMART Audio system...
-
Page 23: Integrating Your Smart Audio System With Your Smart Board Interactive Whiteboard System
SMART software Your SMART Audio classroom amplification system operates without additional software. However, installing the SMART Audio software suite enables you to do the following: • Access SMART Audio volume settings through SMART Notebook™ collaborative learning software or a desktop icon. - Page 24 CH AP TE R 3 Integrating your SMART Audio system with your SMART Board interactive whiteboard system 4. If your computer doesn’t have SMART Notebook software installed, place the included SMART Notebook software CD in your computer. 5. Follow the on-screen instructions to install SMART Notebook software.
-
Page 25: Hardware Environmental Compliance
There are special regulations that must be met when shipping a product that has a lithium ion battery packaged with the product or shipping a lithium ion battery. When returning a SMART Technologies product which contains a lithium ion battery or returning a lithium ion battery, call SMART Technologies RMA for information on these special dispatch regulations: •... -
Page 26: Packaging
US Consumer Product Safety Improvement Act The United States has enacted the Consumer Product Safety Improvement Act which limits the lead (Pb) content in products used by children. SMART Technologies is committed to complying with this initiative. California Air Resources Board –... - Page 28 Freephone 1 866 518 6791 (US/Canada) or +1 403 228 5940 www.smarttech.com www.smarttech.com/contactsupport...
