- Page 1 Freezer User manual FNE 1074...
- Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.
-
Page 3: Table Of Contents
CONTENTS 1 Your Freezer 4 Preparation 2 Important Safety 5 Using Your Freezer Warnings LED indicators and control panel ..16 Intended use ..........4 Setting the operating temperature .16 General safety ...........4 6 Maintenance and For products with a ........7 cleaning water dispenser;... -
Page 4: Your Freezer
Your Freezer Reflectors Top trim Fast-Freeze switch Indicator lights Thermostat knob Ice bank Freezer fan Fast-freeze compartment Frozen-food compartments Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models. -
Page 5: Important Safety Warnings
Important Safety Warnings Please review the following freezer compartment! (This information. Failure to observe may cause frostbite in your this information may cause mouth.) injuries or material damage. • For products with a freezer Otherwise, all warranty and compartment; Do not put reliability commitments will... - Page 6 • Electrical safety of your • Electrical devices must be freezer shall be guaranteed repaired by only authorised only if the earth system in persons. Repairs performed by your house complies with incompetent persons create a standards. risk for the user. •...
- Page 7 Bending cable may cause fire. should not be kept in the Never place heavy objects on freezer. power cable. Do not touch the • If not to be used for a long plug with wet hands when time, freezer should be plugging the product unplugged.
-
Page 8: For Products With A
For products with a Compliance with WEEE Directive and Disposing of water dispenser; the Waste Product: • Pressure for cold water inlet shall be maximum 90 This product complies psi (6.2 bar). If your water with WEEE pressure exceeds 80 psi (5.5 Directive (2012/19/ bar), use a pressure limiting... -
Page 9: Hc Warning
Things to be done for collection points designated by the local authorities. energy saving Do not forget... • Do not leave the doors of your Any recycled substance is an freezer open for a long time. indispensable matter for nature •... -
Page 10: Installation
Installation Please remember that the manufacturer shall not be held liable if the information given in the instruction manual is not observed. Points to be considered when re-transporting your freezer 1. Your freezer must be emptied and cleaned prior to any transportation. 2. -
Page 11: Electric Connection
Electric connection Disposing of your old freezer Connect your product to a grounded socket which is being protected by a Dispose of your old freezer without fuse with the appropriate capacity. giving any harm to the environment. Important: • You may consult your authorised •... -
Page 12: Adjusting The Feet
Adjusting the feet If your freezer is unbalanced; You can balance your freezer by turning the front legs as shown in the illustration below. The corner where the leg exists is lowered when you turn it in the direct ion of black arrow and raised when you turn in the opposite direction. -
Page 13: Reversing The Doors
Reversing the doors Proceed in numerical order 60° 60°... -
Page 14: Reversing The Doors
Reversing the doors Proceed in numerical order 595 mm 55 mm... -
Page 15: Preparation
Preparation Your freezer should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. The ambient temperature of the room where you install your freezer should at least be 10°C. -
Page 16: Using Your Freezer
Using Your Freezer 1 = Lowest cooling setting (Warmest The normal storage temperature of setting) your appliance should be -18 °C (0 °F). MAX. = Highest cooling setting Lower temperatures can be obtained (Coldest setting) by adjusting the thermostat knob towards Position MAX. -
Page 17: Led Indicators And Control Panel
Setting the operating temperature LED indicators and control Red Indicator (3) Illuminates: panel ) If the pre-set temperature can not be maintained. There are three coloured indicator ) If excessive amounts of fresh food lights located on the front of the are placed inside. - Page 18 operating temperature off and “click” sound will be heard. regulated by the temperature control. Lower temperatures can be obtained by adjusting the thermostat knob Cold Warm towards Position 4. recommend checking temperature with a thermometer to ensure that the storage compartments are kept to the desired temperature.
- Page 19 Let the ice cubes slightly thaw Attention instead, or put the bottom of the tray Keep the already deep-frozen food in hot water for a short moment. always separated with freshly placed food. Fast freeze When deep-freezing hot food, the If large amounts of fresh food are cooling compressor will work until the going to be frozen, push the fast...
-
Page 20: Maintenance And Cleaning
Maintenance and cleaning Never use gasoline, benzene or To remove door racks, remove all the similar substances for cleaning contents and then simply push the purposes. door rack upwards from the base. We recommend that you unplug the Never use cleaning agents or water appliance before cleaning. -
Page 21: Recommended Solutions For The Problems
Recommended solutions for the problems Please review this list before calling the service. It might save you time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. - Page 22 The fridge is running frequently or for a long time. • Your new product may be wider than the previous one. This is quite normal. Large freezers operate for a longer period of time. • The ambient room temperature may be high. This is quite normal. •...
- Page 23 Temperature in the fridge or freezer is very high. • The fridge temperature might have been adjusted to a very high degree. Fridge adjustment has an effect on the temperature of the freezer. Change the temperature of the fridge or freezer until the fridge or freezer temperature reaches to a sufficient level.
- Page 24 The door is not closing. • Food packages may prevent the door's closing. Replace the packages that are obstructing the door. • The freezer is not completely upright on the floor and rocking when slightly moved. Adjust the elevation screws. •...
- Page 25 57 4793 0000/AF www.beko.com.au...
